Mitsubishi MXZ-2C20NAHZ4 Handleiding
Pagina's 156 Warmtepomp
Bekijk de handleiding van Mitsubishi MXZ-2C20NAHZ4 gratis online of download de PDF. 30 mensen vonden deze handleiding nuttig. Vraag over dit model? Stel een vraag
PARTS CATALOG (OBB702)
SERVICE MANUAL
OUTDOOR UNIT
Models
MXZ-2C20NA2-
U1
,
U4
MXZ-2C20NAHZ
MXZ-2C20NA3
-
U1
MXZ-2C20NAHZ2-
U1
MXZ-2C20NA4-
U1
MXZ-2C20NAHZ3-
U1
MXZ-3C24NAMXZ-2C20NAHZ4-
U1
MXZ-3C24NA2-
U1
MXZ-3C24NAHZ
MXZ-3C24NA3
-
U1
MXZ-3C24NAHZ2-
U1
MXZ-3C24NA4-
U1
MXZ-3C24NAHZ3-
U1
MXZ-3C30NAMXZ-3C24NAHZ4-
U1
MXZ-3C30NA2-
U1
MXZ-3C30NAHZ
MXZ-3C30NA3
-
U1
MXZ-3C30NAHZ2-
U1
MXZ-3C30NA4-
U1
MXZ-3C30NAHZ3-
U1
MXZ-4C36NAMXZ-3C30NAHZ4-
U1
MXZ-4C36NA2-
U1
MXZ-4C36NA3-
U1
MXZ-4C36NA4-
U1
MXZ-5C42NA
MXZ-5C42NA2
-
U1
MXZ-5C42NA3-
U1
MXZ-5C42NA4-
U1
No. OBH702
REVISED EDITION-R
Indoor unit service manual
MSZ-FE·NA Series (OBH542)
MSZ-FH·NA Series (OBH683)
MSZ-GE·NA Series (OBH548)
MSZ-GL·NA Series (OBH732)
MSZ-EF·NA Series (OBH736)
MSZ-FS·NA Series (OBH872)
MFZ-KA·NA Series (OBH568)
MFZ-KJ·NA Series (OBH752)
SLZ-KA·NA Series (OCH487)
SLZ-KF·NA.TH Series (OCH669)
PLA-A·BA Series (OCH420)
PLA-A·EA Series (OCH640)
SEZ-KD·NA Series
PEAD-A·AA Series
PCA-A·KA Series (OCH455)
MVZ-A·AA Series
SVZ-KP·NA Series (MD-1404-K019)
CONTENTS
• INDOOR / OUTDOOR UNIT
COMPATIBILITY TABLE ······················4
1. TECHNICAL CHANGES ······························8
2. SAFETY PRECAUTION ·······························9
3. PART NAMES AND FUNCTIONS ················13
4. SPECIFICATION ······································14
5. NOISE CRITERIA CURVES ························33
6. OUTLINES AND DIMENSIONS ···················36
7. WIRING DIAGRAM ···································42
8. REFRIGERANT SYSTEM DIAGRAM ···········65
9. DATA ······················································78
10. ACTUATOR CONTROL ···························109
11. SERVICE FUNCTIONS ·····························110
12. TROUBLESHOOTING ······························113
13. DISASSEMBLY INSTRUCTIONS ···············144
HFC
utilized
R410A
MXZ-3C24NA MXZ-3C30NA MXZ-4C36NA
MXZ-3C24NA2 MXZ-3C30NA2 MXZ-4C36NA2
MXZ-3C24NA3 MXZ-3C30NA3 MXZ-4C36NA3
MXZ-3C24NA4 MXZ-3C30NA4 MXZ-4C36NA4
OBH702 REVISED EDITON-H is void.
Revision R:
• INDOOR / OUTDOOR UNITCOMPATIBILITY
TABLE, 4. SPECIFICATION and 9. DATA
have been modied.
