Mikrotik CCR2004-16G-2S+ Handleiding
Pagina's 3 Nederlands Router
Bekijk de handleiding van Mikrotik CCR2004-16G-2S+ gratis online of download de PDF. 27 mensen vonden deze handleiding nuttig. Vraag over dit model? Stel een vraag
CCR2004-16G-2S+
CCR2004-16G-2S+
CCR2004-16G-2S+
CCR2004-16G-2S+CCR2004-16G-2S+
CCR2004-16G-2S+
Safety Warnings
Before you work on any equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for preventing
accidents.
Ultimate disposal of this product should be handled according to all national laws and regulations.
The Installation of the equipment must comply with local and national electrical codes.
This unit is intended to be installed in the rackmount. Please read the mounting instructions carefully before beginning installation. Failure to use the
correct hardware or to follow the correct procedures could result in a hazardous situation to people and damage to the system.
This product is intended to be installed indoors. Keep this product away from water, fire, humidity or hot environments.
Use only the power supply and accessories approved by the manufacturer, and which can be found in the original packaging of this product.
Read the installation instructions before connecting the system to the power source.
We cannot guarantee that no accidents or damage will occur due to the improper use of the device. Please use this product with care and operate at your
own risk!
In the case of device failure, please disconnect it from power. The fastest way to do so is by unplugging the power plug from the power outlet.
It is the customer's responsibility to follow local country regulations, including operation within legal frequency channels, output power, cabling
requirements, and Dynamic Frequency Selection (DFS) requirements. All Mikrotik devices must be professionally installed.
Quick start
Connect your PC to the MGMT/BOOT port;
Connect the device to a power source;
Configure the IP settings of your network card to 192.168.88.2/24;
Configuration should be made using WebFig in a web browser or the WinBox configuration tool;https://mt.lv/WinBox
Openin a web browser to start setup. If the IP address is unavailable, use WinBox and choose the "Neighbors" tab to find the http://192.168.88.1
device. Proceed to connect using the MAC address. The username is "admin", and there is no password (or, for some models, check user and
wireless passwords on the sticker);
For a manual update, visit the products page atto find your product. The required packages are accessible under https://mikrotik.com/products
the "Support&Downloads" menu;
Upload downloaded packages to the WebFig or WinBox "Files" menu and reboot the device;
By upgrading your RouterOS software to the latest version, you can ensure optimal performance, stability, and security updates;
Set up your router password.
Powering
Product specificaties
| Merk: | Mikrotik |
| Categorie: | Router |
| Model: | CCR2004-16G-2S+ |
| Kleur van het product: | Wit |
| Breedte: | 443 mm |
| Diepte: | 44 mm |
| Hoogte: | 210 mm |
| Stroom: | 0.9 A |
| Frequentie van processor: | 1700 MHz |
| Generatie mobiel internet: | Nee |
| Type stroombron: | AC |
| Aantal Ethernet LAN (RJ-45)-poorten: | 1 |
| Aantal USB-aansluitingen: | 1 |
| Certificering: | CE, EAC, ROHS |
| USB-versie: | 3.2 Gen 1 (3.1 Gen 1) |
| Intern geheugen: | 4096 MB |
| Intern geheugentype: | DDR4 |
| Duurzaamheidscertificaten: | RoHS |
| Type processor: | Ja |
| SIM-kaartsleuf: | Nee |
| 3G/4G USB modem compatibiliteit: | Nee |
| Ethernet LAN, data-overdrachtsnelheden: | 10,100,1000 Mbit/s |
| Bekabelingstechnologie: | 10/100/1000Base-T(X) |
| Processorfabrikant: | Annapurna Labs |
| Rack-montage: | Ja |
| Ethernet WAN: | Ja |
| Flash memory: | 128 MB |
| Ethernet interface type: | 16 Gigabit Ethernet |
| Mean time between failures (MTBF): | 200000 uur |
| Aantal Gigabit Ethernet (koper)-poorten: | 16 |
| DSL WAN: | Nee |
| Aantal moduleslots SPF: | 2 |
| Full duplex: | Ja |
| Rackcapaciteit: | 1U |
| AC-ingangsspanning: | 100 - 240 V |
| AC-ingangsfrequentie: | 50/60 Hz |
| Stroomverbruik (typisch): | 48 W |
| Bedrijfstemperatuur (T-T): | -20 - 60 °C |
| Code geharmoniseerd systeem (HS): | 85176990 |
| Temperatuurbewaking: | Ja |
| Aantal geïnstalleerde SFP+ modules: | 2 |
| Spanningsbewaking: | Ja |
