Pagina 1/40
INSTALLATION INSTRUCTIONS FOR PART INST-7800
APPLICATIONS
METRA. The World’s best kits.
™
metraonline.com1-800-221-0932
© COPYRIGHT 2004-2011 METRA ELECTRONICS CORPORATION
REV. 9/20/2013 INST-7800
CAUTION: Metra recommends disconnecting the
negative battery terminal before beginning any
installation. All accessories, switches, and especially
air bag indicator lights must be plugged in before
reconnecting the battery or cycling the ignition.
NOTE: Refer to the instructions included with the
aftermarket radio.
• 99-7888 • 99-7889
• 99-7890 • 99-7891
• 99-7892 • 99-7893
• 99-7894 • 99-7895
Refer to each section title page.
INSTALLATION INSTruCTIONS
TOOLS requIred
Acura/Honda 1990-1998
INST-7800
See application list inside
Installation Instructions Section
-99-7888..............................................................1.0
-99-7889.............................................................2.0
-99-7890.............................................................3.0
-99-7891.............................................................4.0
-99-7892.............................................................5.0
-99-7893.............................................................6.0
-99-7894.............................................................7.0
-99-7895.............................................................8.0
Contents
99-7888
AcuraIntegra 1990-1993
AcuraIntegra 1994-2000
AcuraLegend 1990
AcuraLegend 1991-1996
AcuraTL 1996-1998
AcuraVigor 1992-1994
HondaAccord 1990-1993
HondaOdyssey 1995-1998
IsuzuOasis 1996-1999
99-7889
HondaPrelude 1992-1995
99-7890/99-7892
AcuraCL 1997-1999
AcuraIntegra 1990-1993
AcuraIntegra 1994-2000
AcuraLegend 1990
AcuraLegend 1991-1996
AcuraTL 1996-1998
AcuraVigor 1992-1994
HondaAccord 1990-1993
HondaAccord 1994-1997
HondaOdyssey 1995-1998
IsuzuOasis 1996-1999
99-7891
HondaCivic 1996-1998
99-7893
HondaCR-V 1997-2000
HondaPrelude 1997-2000
99-7894/99-7895
HondaAccord 1998-2000
APPLICATION OvervIew
INST-7800 is a collection of installation instruction booklets.
Use the Application Overview when selecting which
installation instruction selection to use. Each section is setup
as a chapter with its own table of contents.
1. 0
1. Remove(3)screwsfromeachsideofthecenter
consoleandremovetheconsole.
2. Remove(2)screwssecuringthefactoryheadunit
tothesub-dashsupportbracket.
3. Slidetheheadunit/pocketassemblyoutand
disconnectthewiring.(FigureA)
4. Locatetheradiohousing.(FigureB)
Continue to kit assembly for
ALL VEHICLES, Section 1
Acura Integra
1990-1993
(Figure A)
Section 1
Acura/Honda/Isuzu
1990-2000
99-7888
•A)Radiohousing•B)Trimplate•C)Radiosupport
•D)Mountingbracket•E)Equalizerdummyplate
•F)Shaftmasks•G)(2)Palnuts
KIT FeATureS
KIT COMPONeNTS
•2-ShaftandDINunitprovisions
•Equalizerprovisions
•Rearsupportprovisions
•Phillipsscrewdriver•Cuttingtool•Socketwrench
TOOLS requIred
BA
Table of Contents
Dash Disassembly
– AcuraIntegra1990-1993.................................... 1.0
– AcuraIntegra1994-2000.................................... 1.1
– AcuraLegend1990............................................. 1.1
– AcuraLegend1991-1996................................... 1.1
– AcuraTL1996-1998........................................... 1.2
– AcuraVigor1992-1994....................................... 1.2
– HondaAccord1990-1993................................... 1.3
– HondaOdyssey1995-1998................................. 1.3
– IsuzuOasis1996-1999....................................... 1.3
Kit Assembly
– 2-Shaftheadunitprovision................................. 1.4
– DINheadunitprovision....................................... 1.5
D E
C
GF
(Figure B)
Dash DisassemblyINST-7800
