Pagina 1/16
METRA. THE WORLD’S BEST KITS.™
© COPYRIGHT 2004-2011 METRA ELECTRONICS CORPORATION
APPLICATIONS
1-800-221-0932
metraonline.com
INSTALLATION INSTRUCTIONS FOR PART 99-9223
REV. 5/1/12
• Phillips screwdriver • T-25 Torx driver
TOOLS REQUIRED
Volvo S60/V70 2001-2004
99-9223
• A) Radio housing
WIRING & ANTENNA CONNECTIONS (sold separately)
Wiring Harness:
• 70-9221 - Harness for select Volvo vehicles 1999-2003
Antenna Adapter:
• 40-VL10 - Adapter cable for select Volvo 1999-up
KIT FEATURES
KIT COMPONENTS
A
• DIN head unit provision with pocket
Table of Contents
Dash Disassembly
–Volvo S60 2001-2004......................................................................................................3
–Volvo V70 2001-2004 ......................................................................................................3
Kit Assembly
–DIN head unit provision with pocket .............................................................................4-5
K PNOWLEDGE IS OWER
Enhance your installation and fabrication skills by
enrolling in the most cognized and spected re re
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for mo information and take steps re
toward a better tomorrow.
Metra recommends MECP
certified technicians
99-9223
CAUTION: Metra recommends disconnecting the negative battery terminal before
beginning any installation. All accessories, switches, and especially air bag indicator
lights must be plugged in before reconnecting the battery or cycling the ignition.
Note: Refer to the instructions included with the aftermarket radio.
1. Unsnap gearshift trim bezel and slide
back. (Figure A)
2. Remove (2) T-25 Torx from climate
control assembly, angle the climate
control panel out, insert fingers between
the console and climate panel and pull
down at the same angle. Remove the
panel (some force may be required).
(Figure B)
3. Remove (2) T-25 Torx from radio bottom
in climate control cavity to remove
radio. (Figure C)
Continue to kit assembly
3
Volvo S60/V70 2001-2004
Dash Disassembly 99-9223
(Figure A)
(Figure C)
(Figure B)
