Pagina 1/16
APPLICATIONS
METRA. The World’s best kits.
™
metraonline.com1-800-221-0932
© COPYRIGHT 2004-2013 METRA ELECTRONICS CORPORATION
REV. 12/3/2013 INST95-5026
CAUTION: Metra recommends disconnecting the
negative battery terminal before beginning any
installation. All accessories, switches, and especially
air bag indicator lights must be plugged in before
reconnecting the battery or cycling the ignition.
NOTE: Refer to the instructions included with the
aftermarket radio.
INSTALLATION INSTRUCTIONS FOR PART 95-5026
• DoubleDINradioprovision
•A)DoubleDINradiohousing•B)DoubleDINbrackets•C)Rearsupportbracket
KIT FEATURES
KIT COMPONENTS
WIRING & ANTENNA CONNECTIONS(soldseparately)
WiringHarness:
•70-5520-Fordharness2003-up
•70-5521-Fordamplifiedharness2003-up
•70-1771-Fordharness1998-up
AntennaAdapter:
•Notrequired
•Phillipsscrewdriver•Socketwrench
TOOLS REQUIRED
Ford/Lincoln/Mercury 2001-2006
95-5026
See application list inside
A
B C
2
Dash Disassembly
-FordMustang2001-2004................................................................................... 2
-FordExpedition(without NAV) 2003-2006.............................................................. 3
-FordExplorer2002-2005.................................................................................... 3
-LincolnNavigator(with NAV, THX amp) 2003-2006................................................. 4
-LincolnNavigator 2003-2006........................................................... 4(without NAV)
-LincolnAviator2003-2005...............................................................................4-5
-MercuryMountaineer2005................................................................................. 3
Kit Assembly
-DoubleDINradioprovision.................................................................................. 5
Table of Contents
Ford
Expedition ................ 2003-2006 (without NAV)
Explorer...................................... 2002-2005
Mustang..................................... 2001-2004
Lincoln
Aviator........................................ 2003-2005
Navigator (with NAV, THX amp)........ 2003-2006
Navigator ................. 2003-2006 (without NAV)
Mercury
Mountaineer............................... 2002-2005
Applications
1. Unclipandremoveshiftlevertrim
panel.(FigureA)
2. Unclipandremovetheentirepanel
surroundingtheradioandclimate
controlsincludingthevents.
3. Remove(2)9/32”screwssecuring
radio.(FigureB)
Continue to kit assembly
Ford Mustang 2001-2004
(Figure B)
(Figure A)
Dash Disassembly 95-502695-5026
3
Dash Disassembly 95-5026
1. Remove(2)9/32”screwsfrom
aboveinstrumentcluster.
(FigureA)
2. Unclipandremoveentirepanel
surroundingradio,climatecontrols,
andinstrumentcluster.(FigureB)
3. Remove(2)9/32”screws
securingradio.
Continue to kit assembly
Ford Expedition 2003-2006(withoutNAV)
1. Unclipandremoveentirepanel
surroundingradioincludingclimate
controlsandvents.(FigureA)
2. Remove(2)9/32”screwssecuring
radio.(FigureB)
Continue to kit assembly
Ford Explorer/Mercury Mounaineer
2002-2005
(Figure B)
(Figure A)
(Figure B)
(Figure A)
