fig. 3a

fig. 3b

fig. 2c

fig. 4

fig. 4b

fig. 5

fig. 3

180º

“OPEN” Button

Bouton “OPEN”

(OUVRIR)

Botón “OPEN”

(ABRIR)

“CLEAR” (C) Button

Bouton “CLEAR”

(

E

FF

ACER

)

Botón “CLEAR”

(BORRAR)

fig. 1

fig. 1b

fig. 1a

Weather

Protective

Cover

Protection

contre les

intempéries

Cubierta

protectora

contra el clima

Key Storage

Compartment

Compartiment

de rangement

des clés

Compartimiento

de almacenamiento

de llaves

Shackle Release

Lever

Levier de

déclenchement

de l’arceau

Palanca de

liberación

del gancho

fig. 4a

Removable

Key Hook

Crochet

amovible

pour les clés

Gancho

de llave

extraíble

fig. 6

fig. 2a

fig. 2b

fig. 2

Operating Instructions:

To open lock box first time

use (fig. 1):

1. Press down “CLEAR” (C) button (fig. 1b).

2. Press down “OPEN” button (fig. 1a).

3. Guide compartment door down to

fully open.

To set a new combination (fig. 2):

1. Open lock box and locate the yellow

Recode Tool.

2. With compartment door open, locate the 12

yellow plastic slotted buttons behind the door

(numbered from 0 to 9 and symbols # and *).

All arrows on buttons should be set to the

“SET OFF” position (fig. 2b).

3. Using the yellow Recode Tool or a small flathead

screwdriver, PUSH and TURN the desired

number/symbol buttons 180° (1/2 turn) (fig. 2c)

to the “SET ON”position (fig. 2a).

IMPORTANT:

* COMBINATION CAN BE 1-12 CHARACTERS

LONG BUT CANNOT USE THE SAME

CHARACTER MORE THAN ONCE.

** BUTTON IS PROPERLY SET WHEN IT

POPS UP. IT SHOULD NOT REMAIN

PUSHED IN.

4. The lock is now set to your

new combination.

5. Save your combination in a safe place

such as masterlockvault.com or record

it below.

To close and lock box (fig. 3):

1. Press down “CLEAR” (C) button (fig. 3a).

2. Enter the combination.

3. Press down and hold “OPEN”

button (fig. 3b).

4. Close compartment door.

To open lock box with set

combination (fig. 3):

1. Press down “CLEAR” (C) button (fig. 3a).

2. Enter the combination.

3. Press down “OPEN” button (fig. 3b).

4. Guide compartment door down

to fully open.

To hang (fig. 4):

1. Open the lock box

(see above instructions).

2. Push the shackle release lever to the right

(fig. 4a) and pull up on the shackle (fig. 4b).

3. Place shackle around door knob or

other object and close shackle until

it clicks.

4. Close the compartment door.

Notes:

1. Always keep weather cover closed to

withstand extreme weather (fig. 5).

2. Use ANTI-JAM hook to hang keys and

prevent loose keys from jamming

the door closed (fig. 6).

Set On

Activé

Activado

Set Off

Désactivé

Desactivado

#5422D

Portable Push Button Lock box

Coffre de rangement pour clés portatif à bouton-poussoir

Caja de seguridad portátil para llaves con botón de contacto

Recode Tool

Outil de reprogrammation

Herramienta de recodificación

SET

ON

SET

OFF

RECODE TOOL

RECODE TOOL
