Keyed Alike

Trailer Lock Set

Instructions

1. Insert key, turn to position and pull

shackle away from ball

2. Insert ball of coupler lock into un-latched

trailer coupler

3. Push shackle toward ball and coupler until the

shackle will advance no further

4. Turn key to position

, and remove key

Contents May Vary

379DAT

2847DAT

6 Locking

Positions

from 9/16"

to 2-3/4"

Swivel Head Receiver Lock - 2866DAT

5/8" Diameter

Pin Fits 2" Receivers, Class III/IV

1/2" Diameter

Pin Fits 1-1/4" Receivers, Class I/II

1. Easy locking. Push lock body onto pin firmly and remove key

2. Weather tough seal and water tight cap protects lock

3. Chrome plated for improved wear and corrosion resistance

4. Solid brass lock cylinder and aluminum cylinder case offer

corrosion resistance

5. Hardened steel pin for strong cut and shear resistance

6. Precision 4-pin tumbler mechanism resists picking

Adjustable Coupler Latch Lock - 2847DAT

Instructions

To Lock

1. After closing coupler latch, insert shackle through

hole in latch.

2. Place lock-body onto shackle and slide until

tight against coupler latch.

To Unlock

1. Insert, turn and hold key in unlocked position,

while sliding lock body off of the shackle.

3489AT

Locking Ball Mount

2867DAT

Interchangeable

Hitch Ball

Other innovative Master Lock

®

products available:

8428DPS

Python Cable

8287DAT

Truck Bed Security

2841AT

Adjustable Ball Mount

When installing this lock, be sure to press

the lock body onto the pin until it is fully

engaged. Pull firmly on the lock body to

confirm engagement.

Lors de l’installation de ce cadenas,

s’assurer de bien insérer la détente

dans le corps du cadenas.

Tirer fermement sur le corps du

cadenas pour confirmer l’insertion

Cuando instale este cerrojo, asegúrese

de presionar la estructura del cerrojo sobre

el pasador hasta que quede totalmente

enganchado. Tire firmemente de

la estructura del cerrojo para confirmar

que quede bien enganchado.

AVERTISSEMENT!

¡ADVERTENCIA!

WARNING!

Key Positions

1. Shackle Slides Freely

2. Shackle is Dead-Locked

2866DAT

PUSH

TO LOCK

SECURITY

™

Limited Lifetime Warranty – www.masterlock.com Oil Occasionally Master Lock Keyway: K1
