RC-206/306--PANEL- Quick Start EUSET

(P/N: -301051QS REV 1)2900

P/N:

2900-301051QS

Rev:

1

Scan for full manual

RC-206/306--PANEL- Quick Start Guide EUSET

This guide helps you install and use your RC-206/306--PANEL-EUSET for the first time.

Step 1: Check what’s in the b ox

1 faceplate

1 UK frame

1 EU frame

1 Quick start guide

Step 2: Install the -206/306--PANEL-SET RCEU

After mounting the device (see attach the frame to the device and www.kramerav.com/downloads/RC-206/306--PANEL-SETEU)

then click in the faceplate as shown in the illustration below:

European Version

We recommend that you use any of the following standard 1 Gang in-wall junction boxes (or their equivalent):

•: 1 Gang in-wall junction box, with a cut-hole diameter of mm and depth that can t in both the device and the connected EU68

cables (DIN 49073).

•: 1 Gang in-wall junction box, 75x75mm (W, H), and depth that can t in both the device and the connected cables UK

(BS 4662).
