KIT-401TEU PANEL SETPANEL SETKIT-401T US PANEL ,

SET Quick Start

P/N:

2900-301353QS

Rev:

1

Scan for full manual

KIT-401T EU PANEL SET KIT-401T US PANEL /

SET Quick Start Guide

This guide helps you install and use your KIT-401T EU PANEL SET / KIT-401T US PANEL SET for the rst

time.

Go to www.kramerav.com/downloads/KIT-401T EU PANEL SETor

www.kramerav.com/downloads/KIT-401T EU PANEL SETto download the latest user manual.

Step 1: Check in the b what’sox

For EU: 1 EU faceplate and 1 UK faceplate

1 Quick start guide

For US: 1 -blank faceplate, 1 -D faceplate, 1 -D frame bracket and 1 -D frame USD USUSUS

Step 2: Install the PANEL SET

After mounting the device (see www.kramerav.com/downloads/KIT-401T EU PANEL SET) mount the faceplates (US)

and frames as shown in the illustrations below:

USD -Version

Eu Version

DECORA® design frames are included in -D models. US

DECORA® is a registered trademark of Leviton Manufacturing Co., Inc.

We recommend that you use any of the following standard 2 gang in-wall junction boxes (or their equivalent):

•: 2 gang US electrical junction boxes. US-D

•: 2 gang -wall junction box, with a cut-hole diameter of 2x68mm and depth that can t in both the device and the EUin

connected cables (DIN 49073).

•: 2 gang in-wall junction box (BS 4662), 135x75mm (W, H) and depth that can t in both the device and the UK

connected cables.

•EU/UK: 2 gang on-wall junction box (use the recommended Kramer -wall box available at on

www.kramerav.com/product/KIT-401T EU PANEL SET
