RC-208/RC-308 EU PANEL SET Quick Start
(P/N: -301052QS REV 1)2900
P/N:
2900-301052QS
Rev:
1
Scan for full manual
RC-208/RC-308 EU PANEL SET Quick Start
Guide
This guide helps you install and use your RC-208/RC-308 EU PANEL SET for the rst time.
Step 1: Check what’s in the b ox
1 faceplate
1 UK frame
1 EU frame
1 Quick start guide
Step 2: Install the -208/RC-308 EU PANEL SET RC
After mounting the device (see attach the frame to the device and www.kramerav.com/downloads/RC-208/RC-308 EU PANEL SET)
then click in the faceplate as shown in the illustration below:
European Version
We recommend that you use any of the following standard 1 Gang in-wall junction boxes (or their equivalent):
•: 1 Gang in-wall junction box, with a cut-hole diameter of mm and depth that can t in both the device and the connected EU68
cables (DIN 49073).
•1 Gang in-wall junction box, 75x75mm (W, H), and depth that can t in both the device and the connected cables UK:
(BS 4662).
