P/N: 2900-301040 Rev 3 www.KramerAV.com

USER MANUAL

MODEL:

PA-240Net

240W Power Amplifier

PA-120Net

120W Power Amplifier


PA-120Net, PA-240Net – Contents
i

Contents
Introduction  1
Getting Started  1
Overview  2
Typical Applications  3
Defining the PA-240Net and PA-120Net Power Amplifier  4
Connecting the PA-240Net  6
Connecting the Output to a Balanced/Unbalanced Stereo Audio Acceptor  7
Connecting a Balanced/Unbalanced Stereo Audio Source to the Balanced Input  8
Connecting to PA-240Net via RS-232  8
RJ-45 Pinout  8
Connecting PA-240Net via the Ethernet Port  9
Operating the PA-240Net  11
Setting the DIP-Switches  11
Adjusting the Master Volume  11
Using the Embedded Web Pages  12
Setting the Speaker Output Parameters  13
Setting the Line Level Output Parameters  15
Selecting Hi-Z Mono Settings  16
Changing Standby Settings  16
Setting Device Parameters  17
Managing Web Page Security  19
Viewing the About Page  21
Using the Web-based Dante Controller  21
Technical Specifications  22
Default Communication Parameters  23
Protocol 3000  24
Understanding Protocol 3000  25
Kramer Protocol 3000 Syntax  26
Protocol 3000 Commands  27
