REV 28-DEC-2020IS-52410-US

We’re here to help 866-558-5706

Hrs: M-F 9am to 5pm EST

1)Pass xture wires from coupling[L] on frame through tube[N]. Screw tube

onto coupling on frame.

2)Pass xture wires through short threaded tube[B] and screw short threaded

tube into top of tube[N].

3)Lower mast[P] down onto tube[N], making sure xture wires and short

threaded tube[B] pass through hole on top of mast.

4)Pass xture wires through coupling[Q] and screw coupling onto short

threaded tube protruding through the top of the mast.

5)Pass xture wires from coupling[Q] through desired number of stems[A] and

short threaded tubes[B]. Screw stems together using short threaded tubes.

NOTE: Thread locking compound must be applied to all stem threads as

noted with (4) symbol to prevent accidental rotaon of xture during

cleaning, relamping, etc.

6)Screw connected stems into coupling.

Fixture Diagram

Parts List

[A]Stems

[B]Short Threaded

Tubes

[C]Swivel

[D]Canopy

[E]Glass

[F]Socket Cover

[G]Mounting Strap

[H]Mounting Screws

[I]Outlet Box

[J]Knobs

[K]Lockwashers

[L]Coupling

[M]Strap Mounting

Screws

[N]Tube

[O]Plastic Tube

[P]Mast

[Q]Coupling

Cauons

CAUTION – RISK OF SHOCK –

Disconnect Power at the main circuit breaker panel or main fusebox before

starng and during the installaon.

WARNING:

This xture is intended for installaon in accordance with the Naonal Electrical

Code (NEC) and all local code specicaons. If you are not familiar with code

requirements, installaon by a cered electrician is recommended.

CLEANING:

•Always be certain that electric current is turned o before cleaning.

•Only a so damp cloth should be used. Harsh cleaning products may damage

the nish.

Installaon Instrucons (connued)

Installaon Instrucons

7)Pass xture wires from last stem through swivel[C]. Swivel should be

installed with the longer end hanging down towards the mounng stems.

8)Screw longer end of swivel into end of last stem.

Note direcon of swivel in accordance with ceiling.

NOTE: Fixture wires should not be cut shorter than 6” from top edge of

canopy.

9)Find the appropriate threaded holes on mounng strap[G] that align with

hole distance in canopy[D]. Assemble mounng screws[H] into threaded

holes.

10)Aach mounng strap to outlet box[I] using the strap mounng screws[M].

Mounng strap can be adjusted to suit posion of xture.

11)Grounding instrucons: (See Illus. a or b).

a)On xtures where mounng strap is provided with a hole and two raised

dimples, wrap ground wire from outlet box around green ground screw,

and thread into hole.

b)On xtures where a cupped washer is provided, aach ground wire from

outlet box under cupped washer and green ground screw, then thread

into mounng strap.

If xture is provided with ground wire, connect xture ground wire to outlet

box ground wire with wire connector aer following the above steps. Never

connect ground wire to black or white power supply wires.

12)Make wire connecon. Reference chart below for correct connecons and

wire accordingly.

Connect Black or Red

Supply Wire to:

Connect White Supply

Wire to:

BlackWhite

*Parallel cord (round &

smooth)

*Parallel cord (square &

ridged)

Clear, Brown, Gold or

Black without Tracer

Clear, Brown, Gold or Black

with Tracer

Insulated wire (other

than green) with copper

conductor

Insulated wire (other

than green) with silver

conductor

*Note: When parallel wire (SPT

1 & SPT 2) are used. The neutral

wire is square shaped or ridged

and the other wire will be round

in shape or smooth (See illus.)

Neutral Wire

13)Push xture to ceiling, carefully passing mounng screws through holes in

canopy.

NOTE: Be certain wires do not get pinched between mounng strap and

canopy, or canopy and ceiling.

14)Use knobs[J] and lockwashers[K] to secure canopy. Tighten to secure.

15)Carefully lower glass[E] down over socket onto base cup.

16)Carefully lower socket cover[F] down over socket.

17)Carefully lower plasc tube[O] onto socket cover and gently apply pressure

to push cover down completely over socket onto inside of glass.

18)Remove plasc tube from socket cover.

19)Repeat for remaining sockets.

20)Insert recommended bulbs (Not supplied).

GREEN GROUND

SCREW

CUPPED

WASHER

OUTLETBOX

GROUND

FIXTURE

GROUND

DIMPLES

WIRE CONNECTOR

OUTLETBOX

GROUND

GREEN GROUND

SCREW

FIXTURE

GROUND

a

b

For warranty informaon please visit: kichler.com/warranty

►

►

►

►

►

P

B

L

E

F

O

A

D

G

H

M

►

C

K

J

I

B

A

Q

N
