Pagina 1/6
NA N O B RO A D B A N D R O U T E R
W I R E L E S S 1 5 0N
1 5 0 M BP S
Q U I C K I N S TA L L AT I O N G U I D E
N I - 7 0 7 5 3 7
LED INDICATORSC O N T E N T S O F T H E P A C K A G E
Before starting the installation fi rst check that all necessary parts are present.
The box should contain:
- Wireless router 150N
- Power Adapter 5V 1A
- CD with manual
- Manual
T E C H N I C A L S P E C I F I C AT I O N S
- Low energy consumption, 1.2W
- USB Powered
- 802.11n wireless protocol
- Compatible with IEEE802.11g and IEEE802.11b
- Supports WEP, WPA/WPA2, TKIP/AES encryption
- IEEE802.1x authentication
- 150 Mbps data transfer rate
- 1x Aerial 2dBi
- Web Based Management
- Supports: Dynamic IP, Static IP, PPPoE
- 1 x WAN, 1 x LAN RJ-45 UTP ports
- Built-in NAT and DHCP server
- Supports: VPN pass through
- Independent of operating system
R A N G E O F A P P L I C AT I O N S
This router allows you to set up a wireless broadband Internet connection on multiple
computers. On top of a shared Internet connection, you can also set up a network
between several PCs. Connect the ADSL modem to the WAN port of the router and after a
few seconds the WAN LED will light up. You can now connect the PCs. Once the PCs have
been started up, the relevant LED will light up.
H A R D W A R E I N S TA L L AT I O N
As soon as you have connected the router to the power adapter, the power
LED (Green) will light up and the WLAN LED will fl ash. The other LEDs (Green) will light up
as soon as one of the UTP port is connected to the computer. When data is transferred
from one computer to another the LEDs will start to fl ash.
If you already have an ADSL connection with
R O U T E R C O N F I G U R A T I O N
After you have correctly connected the router, you can start to confi gure it. For some
providers you will need addition information, such as your username and a password.
Start up the Internet browser and enter the following address in the address bar
http://192.168.2.1 and press “Enter”
The following screen is displayed. To access the router enter “admin” for username and
“1234” for password and then click “OK”
After clicking “OK” the router setup screen is displayed.
Click on “Quick Setup” and then click on “Next”. Select your Internet connection, and
after your provider has given you a username and password, which is needed for cable
connections, select the PPPoE option.
