32"
813mm
1" IPS
FEMALE
SUPPLY
INLET
REMOVABLE
ACCESS PANELS
(NOT SHOWN)
1" IPS BRASS
STAY OPEN
BALL VALVE
WITH INLET
AND OUTLET
UNION
22"
559mm
(34-1/2")
(876mm)
(46")
(1168mm)
1"
25mm
FLANGE
ALL AROUND
PULL DOWN
TO OPEN
EYE/FACE WASH
18-7/16"
468mm
22-1/8"
562mm
TO FINISHED FLOOR
(BOTTOM OF
ROUGH IN)
30-1/4"
768mm
SHOWER
"PANIC BAR"
IN THE OFF POSITION
82"-96"
2083mm-2438mm
ACTIVATION
POSITION
6X
Ø3/16"
4.8mm
MOUNTING
HOLE
3-1/2"
89 mm
FLOOR LINE
WASTE CONNECTION MUST ADHERE TO LOCAL HEALTH AND PLUMBING CODES.
WHEN INSTALLING THIS UNIT, LOCAL, STATE OR FEDERAL CODES SHOULD BE ADHERED TO.
FLOW RATE FOR EYE/FACE WASH IS 3.7 GPM AND EXCEEDS ANSI STANDARD Z358.1.
DIMENSIONS MAY VARY BY ± 1/2" [12.7mm].
*
4.
NOTES:
1.
3.
4X
4-1/2"
114mm
20-1/8"
511mm
2-5/8"
67mm
1-7/8"
48mm
23-5/16"
592mm
ø 10-1/2"
267mm
FLANGE
HANGER BRACKET
(NOT SUPPLIED)
(5-3/4") (146mm)
1" S.S. ELBOW
(SUPPLIED)
1 X 36" S.S. NIPPLE
(SUPPLIED)
ESCUTCHEON
(SUPPLIED)
1" IPS AND FITTINGS
(NOT SUPPLIED)
36"
914mm
*
MOUNTING HARDWARE NOT SUPPLIED.5.
DWG. NO.
APPROVED:
DRAWN:
PART NUMBER:
DRAWING NO.:
SCALE:SHEETOF
REV.
DRAWING TYPE:
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
SIZE:
BY:ECN NO.
DATE:
DATE:
ECN:
REVISED PER
CHK'D.:
Haws Corporation - All Rights Reserved
HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
C
R
SPARKS, NEVADA 89431
(775) 359-4712 FAX (775) 359-7424
1455 KLEPPE LANE
E-MAIL: HAWS@HAWSCO.COM
WEBSITE: WWW.HAWSCO.COM
MODEL(S)
15913A00
I. ROBERTS
7/13/10
15913A004
0002080142.D
8355WCW
1/18
1
1
A
4290
HM
INSTALLATION
4734
2012
(31-5/8")
(803mm)
STAINLESS STEEL
SHOWER HEAD
WITH 20 GPM FLOW CONTROL
2
HANGER BRACKET
(NOT SUPPLIED)
11"
SIMULTANEOUS USE BY THE SAME USER PER ANSI Z358.1.
SHOWER HEAD MUST BE POSITIONED IN-LINE WITH EYE/FACEWASH TO ALLOW FOR2
