Haws 8356WCDD Handleiding

Bekijk gratis de handleiding van Haws 8356WCDD (1 pagina’s), behorend tot de categorie Niet gecategoriseerd. Deze gids werd als nuttig beoordeeld door 6 mensen en kreeg gemiddeld 4.1 sterren uit 2 reviews. Heb je een vraag over Haws 8356WCDD of wil je andere gebruikers van dit product iets vragen? Stel een vraag

32"

813mm

1-1/2" O.D.

DRAIN TAILPIECE

1" IPS

FEMALE

SUPPLY

INLET

REMOVABLE

ACCESS PANELS

(NOT SHOWN)

1" IPS BRASS

STAY OPEN

BALL VALVE

WITH INLET

AND OUTLET

UNION

OPTIONAL SHOWER HEAD

STAINLESS STEEL

SHOWER HEAD

WITH 20 GPM FLOW CONTROL

HANGER BRACKET

(NOT SUPPLIED)

"PANIC BAR"

FOR ACTIVATING

EYE/FACE WASH

1 X 22" S.S. NIPPLE

(SUPPLIED)

ESCUTCHEON

(SUPPLIED)

SUSPENDED

CEILING

22"

559mm

INSTALLATION

6X

Ø3/16"

4.8mm

MOUNTING

HOLE

4X

4-1/2"

114mm

4"

102mm

20-1/8"

511mm

2-5/8"

67mm

1-7/8"

48mm

23-5/16"

592mm

2-11/16"

68mm

1 X 5" GALV. NIPPLE

(SUPPLIED)

(9-1/2") (241mm)

ø 10-1/2"

267mm

FLANGE

FLOOR LINE

30-1/4"

768mm

1"

25mm

FLANGE

ALL AROUND

18-3/4"

476mm

PULL DOWN

TO OPEN

EYE/FACE WASH

(BOTTOM OF

ROUGH IN)

FLOW RATE FOR EYE/FACE WASH IS 3.7 GPM AND EXCEEDS ANSI STANDARD Z358.1.

WHEN INSTALLING THIS UNIT, LOCAL, STATE OR FEDERAL CODES SHOULD BE ADHERED TO.

WASTE CONNECTION MUST ADHERE TO LOCAL HEALTH AND PLUMBING CODES.

1" IPS

(NOT SUPPLIED)

3-1/2"

89 mm

10"

254mm

ACTIVATION

POSITION

SHOWER

"PANIC BAR"

IN THE OFF POSITION

82"-96"

2083mm-2438mm

34"

864mm

RECOMMENDED

NOTES:

DIMENSIONS MAY VARY BY ± 1/2" [12.7mm].4.

3.

1.

MOUNTING HARDWARE NOT SUPPLIED.

*

5.

*

21-7/8"

556mm

TO FINISHED FLOOR

(34-5/8")

(879mm)

(47-1/2")

(1206mm)

DWG. NO.

APPROVED:

DRAWN:

PART NUMBER:

DRAWING NO.:

SCALE:SHEETOF

REV.

DRAWING TYPE:

THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS

MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.

SIZE:

BY:ECN NO.

DATE:

DATE:

ECN:

REVISED PER

CHK'D.:

Haws Corporation - All Rights Reserved

HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.

C

R

SPARKS, NEVADA 89431

(775) 359-4712 FAX (775) 359-7424

1455 KLEPPE LANE

E-MAIL: HAWS@HAWSCO.COM

WEBSITE: WWW.HAWSCO.COM

MODEL(S)

15915A00

I. ROBERTS

7/12/10

15915A006

0002080154.D

8356WCDD

1/18

11

A

4290PF

INSTALLATION

4842

2013

(29-5/8")

(752mm)

EXTERNAL

DRAIN COVER

SEE DETAIL "A"

SHOWER HEAD MUST BE POSITIONED IN-LINE WITH EYE/FACEWASH HEAD TO ALLOW FOR

SIMULTANEOUS USE BY THE SAME USER PER ANSI Z358.1.

2

2

11"

BALL

DETENT

2X

IN-LINE STRAINER

HOUSING

Product specificaties
