32"

813mm

1" IPS

FEMALE

SUPPLY

INLET

REMOVABLE

ACCESS PANELS

(NOT SHOWN)

1" IPS BRASS

STAY OPEN

BALL VALVE

WITH INLET

AND OUTLET

UNION

OPTIONAL SHOWER HEAD

STAINLESS STEEL

SHOWER HEAD

WITH 20 GPM FLOW CONTROL

HANGER BRACKET

(NOT SUPPLIED)

1 X 22" S.S. NIPPLE

(SUPPLIED)

ESCUTCHEON

(SUPPLIED)

SUSPENDED

CEILING

22"

559mm

INSTALLATION

ø 10-1/2"

267mm

FLANGE

(9-1/2") (241mm)

1 X 5" GALV. NIPPLE

(SUPPLIED)

(34-1/2")

(876mm)

(46")

(1168mm)

1"

25mm

FLANGE

ALL AROUND

PULL DOWN

TO OPEN

EYE/FACE WASH

18-7/16"

468mm

22-1/8"

562mm

TO FINISHED FLOOR

(BOTTOM OF

ROUGH IN)

30-1/4"

768mm

SHOWER

"PANIC BAR"

IN THE OFF POSITION

82"-96"

2083mm-2438mm

34"

864mm

RECOMMENDED

ACTIVATION

POSITION

10"

254mm

6X

ø3/16"

4.8mm

MOUNTING

HOLE

3-1/2"

89 mm

1" IPS

(NOT SUPPLIED)

FLOOR LINE

WASTE CONNECTION MUST ADHERE TO LOCAL HEALTH AND PLUMBING CODES.

WHEN INSTALLING THIS UNIT, LOCAL, STATE OR FEDERAL CODES SHOULD BE ADHERED TO.

FLOW RATE FOR EYE/FACE WASH IS 3.7 GPM AND EXCEEDS ANSI STANDARD Z358.1.

DIMENSIONS MAY VARY BY ± 1/2" [12.7mm].4.

NOTES:

1.

3.

4X

4-1/2"

114mm

20-1/8"

511mm

2-5/8"

68mm

1-7/8"

48mm

23-5/16"

592mm

IN-LINE STRAINER

MOUNTING HARDWARE NOT SUPPLIED.5.

*

*

DWG. NO.

APPROVED:

DRAWN:

PART NUMBER:

DRAWING NO.:

SCALE:SHEETOF

REV.

DRAWING TYPE:

THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS

MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.

SIZE:

BY:ECN NO.

DATE:

DATE:

ECN:

REVISED PER

CHK'D.:

Haws Corporation - All Rights Reserved

HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.

C

R

SPARKS, NEVADA 89431

(775) 359-4712 FAX (775) 359-7424

1455 KLEPPE LANE

E-MAIL: HAWS@HAWSCO.COM

WEBSITE: WWW.HAWSCO.COM

MODEL(S)

15911A00

I. ROBERTS

7/13/10

15911A004

0002080140.D

8355WCC

1/18

11

A

4290HM

INSTALLATION

4734

2012

(31-5/8")

(803mm)

SIMULTANEOUS USE BY THE SAME USER PER ANSI Z358.1.

SHOWER MUST BE POSITIONED IN-LINE WITH EYE/FACEWASH HEAD TO ALLOW FOR2

2

11"

1"IPS

(NOT SUPPLIED)
