1000003593 (Rev. B - 04/17)

37 1/2"

953mm

23-1/4" TO 23-1/2"

(591mm TO 597mm)

PROVIDES

35-3/4" TO 36"

(908mm TO 914mm)

ORFICE HEIGHT

CHECK LOCAL

CODES

17 1/4"

438mm

BACK OF WALL

TO BE 12"

(305mm) MIN.

DEPTH

FLOOR LINE

WOOD OR STEEL

FRAME SHOWN

(NOT PROVIDED)

IMPORTANT:

DOUBLE STUD OR 3 INCHES (76 mm)

BETWEEN MOUNTING FRAMES

IF PLACED NEXT TO ANOTHER

BOTTLE FILLER, FOUNTAIN OR WALL

FRONT PANEL

FRAME

BASIN

*

1. 17-1/4” (438mm) W x 37-1/2” (953mm) H and (*23-1/4” (591mm) for Cut a square rectangular wall opening

ADA)abovenishedoor.

2. Reinforce the wall openingonallsidessothatitwilladequatelysupportthefountain.Thisreinforcement

mustsupportupto150lbsstaticloadandprovideameansforsecuringtheframeassemblyinplace.

730873251730 MOUNTING FRAME INSTRUCTIONS

ForTechnicalService,pleasecontactusat1.800.476.4106

www.halseytaylor.com

3. Remove frame and related hardware frompackaging.Installtheframesquarelyinwallopeningwithframe

uprightedgesushwiththenishedwallface.Securetheframesidesandtoptothewallusing(10)5/16”bolts

orscrews(notprovided).

NOTE:Besurethatframeissquaredinlocation.Donotuselessthantherequiredscrewquantityandsize.

NOTE:Accesstotherearofthefountainisdesirabletoeaseinstallation.Ifrearaccessisnotobtainablean

accesspanel(furnishedbyothers)shouldbeinstalledbelowthefountain.
