IMPORTANT:
•ALLINSTALLATIONWORKSHOULDBEDONEBYACCREDITEDPROFESSIONAL.
•SHUTOFFPOWERSUPPLYATFUSEORCIRCUITBREAKER!
•USEONLYTHESPECIFIEDBULBS.DONOTEXCEEDTHEMAXIMUMWATTAGE!
CONNECTING THE WIRES
4.Attachthexture’swirestothepowersupplywiresfromthejunctionbox.Connectblacktoblack(orsmooth);whitetowhite(or
ribbed);groundtoground(greenorcopper).Twisttheendsofthewirepairstogether,thentwistonawireconnector.Makesureall
twistsareinthesamedirection.Ifthereisnogroundwire(greenorcopper)fromthejunctionbox,locategroundscrew(E)onmounting
strap(B)andwrapthexture’sgroundwirearoundthegreengroundscrew(E).Useascrewdrivertosecuregroundscrew(E)ontothe
mountingbracket.Tuckallwiresneatlyintothejunctionbox.
FINISHING THE INSTALLATION
5.Placebackplate(F)overmountingstrap(B)sothatmountingscrews(D)protrudethroughtheholesinbackplate(F).Securethe
backplatetothemountingstrapwithdecorativenuts(H).Twistuntilthebackplateofthextureissnugagainstthewall.
6.
Installalightbulb(notprovided)inaccordancewiththexture’sspecications.Donotexceedthemaximumrecommended
wattage.
7.Loosenthumbscrew(I).Tilttheglassshade(M)anddecorativecap(K)slightly,andglassshade(M)anddecorativecap(K)
overthelamp.Straightendecorativecap(K)andlid(J)ontopofglassshade(M)checkingthateverythingislevelandsecurethe
assemblybytighteningthumbscrew(I).
Yourinstallationiscomplete.Turnonthepowerandtestthexture.
For Customer Service, please
contact the place of purchase.
A:ssemblyInstructions(Dixon)3218-1W & 3219-1W
CLEANING TIPS
Treat the xture gently! Regular cleaning will reduce the need for deep cleaning. For regular cleaning, turn off the light and wipe down the
xture with a clean lint-free cotton or microber cloth. Never spray cleaner directly onto the xture.
PREPARING FOR INSTALLATION
Removeallofthecontentsfromthecarton.Seetheimportantnotesabove.Shutoffthepoweratthecircuitbreakerandcompletely
removetheoldxturefromthewall,includingtheoldmountingstrap.
1.Mountingstrap(B)containsseveralpairsofthreadedholesandtwoofmountingscrews(D).Youmayneedtotightenhexnuts(C)
thatholdthescrewsinplace.
2.Placemountingstrap(B)uptoyourjunctionbox.Placebackplate(F)overthemountingstrapliningupmountingscrews(D)withthe
holesinbackplate(F).Thiswillallowyoutoensurethatyouarehangingthexturestraight.
3.Pullthehousewiresthroughthecenterofmountingstrap(B).Securemountingstrap(B)tothejunctionboxwithmountingscrews
(A)andascrewdriver.Tightenthescrewssecurely.
House Wires
Fixture Wires
Hot
How to Identify the Fixture’s Wires
HotNeutralGround
Smooth
Ribbed
Bare Metal,
Green, or
Green Inner
Thread
Black
White
Black Inner
Thread
White Inner
Thread
FE
A
H
B
D
C
J
L
K
I
M
G
