1

IMPORTANT:

I

I

I

IM

M

M

MP

P

P

PO

O

O

ORT

RT

RT

RTA

A

A

AN

N

N

NT:

T:

T:

T:

Go to www.extron.com for the complete

user guide, installation instructions, and

specifications before connecting the

product to the power source.

DTP DVI 330 • Setup Guide

This guide provides quick start instructions for an experienced installer to set up and operate the Extron DTP DVI 330 digital video

extender. The DTP DVI 330 transmitter and receiver pair can extend an HDCP-compliant DVI signal up to 330 feet (100 m).

Installation

Step 1 — Mounting

Turn off or disconnect all equipment power sources and mount the Tx and Rx units as required.

Step 2 — Connections

a

— Connect an DVI cablebetween this port and the DVI output port of the digital videosource.DVI Input connector (Tx)

b

— If desired, connect a DVI monitor for local monitoring of the input digital image.Local Output connector (Tx)

c

— Connect an unbalanced stereo audio source to this 3.5 mm mini stereo jack for an analog audio input.Audio input (Tx)

d

(both units) — To pass serial or infrared data or control signals, RS-232 and IR connectors

such as serial control of a projector, connect the primary device to the transmitter and the

secondary device to the receiver via the RS-232 and IR captive screw connectors on both

units.

e

(both units) — Connect transmitter DTP Out to receiver DTP In. DTP RJ-45 connectors

Extron recommends that you terminate both cable ends in accordance with the following

specifications, at a minimum:

• •TIA/EIA T 568 B CAT 6A, shielded •24 AWG, solid conductor

ATTENTION:

• Do not connect these devices to a computer data or telecommunications network.

• Ne connectez pas ces appareils à un réseau de télécommunications ou de données

informatiques..

Sig(nal) LED (both units) — Lights when the unit is receiving a TMDS clock signal on the DVI input

(transmitter) or any valid signal on the DTP In connector (receiver).

Link LED (both units) — Lights when a valid link is established between the units on the DTP cable.

f

— Connect a display with an DVI input for display of the transmitted direct digital image.DVI Output connector (Rx)

g

— Connect a balanced or unbalanced stereo or mono audio device to the receiver via the Audio Audio Output connector (Rx)

captive screw connector. See the

drawing on page 2.

DTP DVI 330 Tx

DTP DVI 330 Rx

L R

OUTPUTS

DVI-D

AUDIO

DTP DVI 330 Rx

INPUTS

LOCAL OUTPUT

AUDIO

DVI-D

DTP DVI 330 Tx

RxGTx

RS-232 IR

RxTx

POWER

12V

0.8 A MAX

SIG LINK

DTPOUT

OVER DTP

RxGTx

RS-232 IR

RxTx

POWER

12V

0.8 A MAX

SIG LINK

DTP IN

OVER DTP

LOCAL

SHARE

REMOTE

1 2

ON

DDC ROUTE

FrontRear

4

8

8

1523

FrontRear

47

65

5

Pin

1

2

3

6

7

8

4

Wire color

White-green

Green

White-orange

White-blue

Orange

White-brown

Brown

Blue

TIA/EIA T

568 B

TP Wires

18234567

Pins:

Ground

Receiv

e pin on connected unit

Tr

ansmit pin on connected unit

Connected RS-232

and IR Device Pins

Tx/Rx

Pins

Receiv

e pin on connected unit

Tr

ansmit pin on connected unit

RxGTx

RS-232 IR

RxTx
