C9

Organ Machine

Congratulations on your purchase of the Electro-Harmonix Organ MachineThe C9 C9.

transforms the tone of a guitar or keyboard into that of a convincing electric organ

yet is easy to use and play. Based on the sound engine found in the EHX B9 Organ

Machine, the C9 delves deeper into the sonic territory of classic organs covering a

vast array of memorable electric organ tonesThe s controls covering . C9ha

percussive attack level, modulation speed, and both organ and dry volume.

WARNING: Your comes equipped with an Electro-Harmonix 9.6DC-200BI power supply C9

(same as used by Boss

®

& Ibanez

®

: 9.6 Volts DC 200mA). The requires 0mA at 9VDC with C910

a center negative plug. Using the wrong adapter or a plug with the wrong polarity may damage

your and void the warranty. C9

GETTING STARTED

Connect the supplied power adapter to the 9V power jack. Plug your instrument into

the INPUT jack; connect your amp to the ORGAN OUTPUTjackSet the DRY knob to .

minimum and all the other top row knobs to about mid positionSelect the preset .

named TONE WHEEL and step on the footswitch to turn on the LED. Play your

instrument and adjust controls to your liking. MOD controls modulation speed and

CLICK controls percussive click level.

DRY VOLUME KNOB

Controls the volume of the untreated instrument the ORGAN OUTPUT jack. at

ORGAN VOLUME KNOB

Controls the overall volume of the ORGAN preset.

MOD KNOB

MOD controls the . Modulation can be completely turned off speed of modulation

when MOD is set fully counterclockwiseThe type of modulation is contingent on the .

preset selected. The different types of modulation available are vibrato, tremolo and

chorus. See the preset descriptions for modulation type.

CLICK KNOB

CLICK controls It was design to simulate the harmonic percussive click level. ed

percussion effect on classic B3 and C3 organs. The click added to the very first is

note or chord played. The click will retrigger only when current notes have been

released and the amplitude falls below a threshold. For most presets, CLICK controls ir

parameters unique to the preset. See the preset descriptions for details.
