Product Descriptions

This is a 4 channels foot control chaser, features 17 built-in chase patterns and 7 fixed scenes,

each pattern has four operating modes: Audio, Fast, Medium and Slow. When linkup, this unit

can be used as a either a Master or Slave. A DMX controller or a foot controller(supplied) can

be used to control this unit after proper connection.

24-004-0918

Rev 1.0

User Instructions

1

2

3

4

5

6

7

8

9

10

11

1. Channel Output: 5A/CH., Total 15A max.

2. Circuit Breaker: 15A

3. Linkup Selector: Move this slider to select between Master and Slave.

4. Function Selector: This slider is used to select Audio/Fast/Medium/Slow mode for the patterns.

5. Channel LEDs: These LEDs indicate the intensity of corresponding channel or activity of the

pattern or scene.

6. Stand By Button: This button serves several functions. In Master mode, tap this button to

activate or deactivate Stand By(its LED flashes when Stand By is active).

Pressing this button for three seconds can activate 17 chase patterns or 7

fixed scenes. When chase patterns are activated, each tap of Pattern button

will select a chase pattern. When the scenes are activated, each tap of Pattern

button will forward a scene step by step.

7. Pattern Button: In Master mode, use this button to select chase pattern or scene.

Control & Functions
