©Elation Professional® www.elationlighting.com SD Disk Drive™ User Manual Page 2

SD Disk Drive™™ Introduction

Introduction: Thank you for purchasing the SD Disk Drive™ from

Elation Professional®, the perfect companion to any Show Designer™

controller. The SD Disk Drive™ is a 19” rack mount accessory that

allows you to back-up and upload vital information to and from any

member of the Show Designer™ family (Show Designer™, Show

Designer 1™, or Show Designer 2™ ). The SD Disk Drive connects

directly to a Show Designer and provides a 3.5” floppy disk drive, a

PS-2 keyboard jack, a MIDI “IN” port, a MIDI “OUT” port, and two RS-

232 jacks. The MIDI connections can be used to connect to other MIDI

devices that use MIDI as a method to back-up memory.

Unpacking: Every SD Disk Drive™ has been thoroughly tested and

has been shipped in perfect operating condition. Carefully check the

shipping carton for damage that may have occurred during shipping.

If the carton appears to be damaged, carefully inspect your unit for

any damage and be sure all accessories necessary to operate the unit

have arrived intact. In the event damage has been found or parts are

missing, please contact our toll free customer support number for fur-

ther instructions. Please do not return this unit to your dealer without

first contacting customer support.

Customer Support:Elation Professional® provides a customer sup-

port line, to provide set up help and to answer any question should you

encounter problems during your set up or initial operation. You may

also visit us on the web at www.elationlighting.com for any comments

or suggestions. Service Hours are Monday through Friday 9:00 a.m. to

5:00 p.m. Pacific Standard Time.

Voice: (323) 582-3322 Fax: (323) 582-2610

E-mail: support@elationlighting.com

Warning! To prevent or reduce the risk of electrical shock or fire, do

not expose this unit to rain or moisture.

Caution!There are no user serviceable parts inside this unit. Do not

attempt any repairs yourself, doing so will void your manufactures war-

ranty. In the unlikely event your unit may require service please contact

Elation Professional.

At Elation Professional

®we are concerned about the environment, and

package all our units in recyclable material. Please do not dispose of

the shipping carton in the trash, recycle whenever possible.

User Instructions

6/03

©Elation Professional®

4295 Charter Street

Los Angeles Ca. 90058

www.elationlighting.com

SD DISK DRIVE
