ARCHITECTURAL
LED Lighting Solutions
ELAR 180 PAR RGBWA Data Sheet
1
www.ElationLighting.com • Toll Free
(
866
)
245-6726
PRODUCT FEATURES
.
. 60 x 3 Watt RGBWA LED’s
(
10° lens)
. 4 Digit LED display
. Manual mode on board Control
. Auto Mode
. Built In Color Macros
. Smooth Color Mixing Flicker Free
. Rugged Die Cast Aluminum Case
. Split Yoke up-light bracket
. IP Power Link up to 4pcs
. Separate logic and LED enclosure
. Waterproof IP65
. Heat sink cooling
TECHNICAL SPECIFICATIONS
. DMX Channels: 4 DMX modes
–�5/6/8/10 Channels
. Control:USITT DMX-512, 3pin DMX in-out
cable supplied and power input
120v AC ppg connector
. Color:Smooth Color Mixing, Camera ready�
. Strobe:25 flashes per second
. Dimmer: 0- 100% Smooth Dimming via DMX�
. Cooling: Convection cooled heat sinks
. Cable Plug Type: IP Power in-out/Data in-out�
. Cables include Edison 120v plug & 3pin XLR’s�
. LED’s Source:60 x 3W Single LXHL
12 Red, 12 Green 12 Blue, 12 White, 12 Amber�
. Lux: 10,930 lux / 1,015 fc @ 8’/2.5m
. LED Life:100,000 hours based on LED
manufactures’ test data
. Approvals: cETLus >pproved
ENVIRONMENTAL SPECIFICATIONS
. Max Ambient Temperature: 113°F/45°C
. IP Level: IP 65
ELECTRICAL SPECIFICATIONS
. Ballast: Electronic Power supply
. Power Supply: 120-240V 50/60Hz
. Power Consumption:185W
. Dimensions: (LxWxH) 8.9” x 10.5” x 9”
/ 226x267x232mm
. Weight: 16.5 lbs. (7.5 Kgs)
Ø 9.1” / Ø 232mm
11.5” / 292.2mm
8.9” / 226.2mm
10.5” / 267mm
