Contents
Refer to the numbered drawings that go with the numbered paragraphs
in the instructions
Introduction 1
Installation 1
Use and Safety 3
Cleaning and hygiene 5
Fault nding 5
Maintenance 6
Compliance with regulations 7
Introduction
1.1 DESCRIPTION
• These electronic beater-mixers are professional bakery and
pastry-making appliances designed for kneading, mixing and
whisking all kinds of food products.
A Stainless steel bowl, 20 or 30 litre capacity
(depending on model)
B Removable safety guard and with additional plastic screen
D Head
E Control panel
G Lift/lower lever
H Planetary gear system
I Column
J Bowl cradle
K Feet
• 3 tools are available as standard supply:
A Hook for kneading.
B Paddle for mixing.
C Whisk for emulsions
• Optional equipment:
- 20 and 30 L reinforced whisk for heavy work.
- Reduction bowl 10 L with 3 tools (20 L model)
- Reduction bowl 10/20 L with 3 tools (30 L model)
Installation
XBB20/30 GB 10 20231
1.1b
GB
10/2023
Introduction
The User Manual contains useful information for the user on how
to work correctly and in complete safety, and is designed to make it
easier to use the machine (called “machine” or “appliance” below).
What follows is in no case intended to be a long list of warnings
and constraints, but rather as a series of instructions meant to
improve the service provided by the machine in every respect,
and particularly to avoid a series of injuries or damage to equip-
ment that might result from inappropriate procedures for use
and management.
It is essential that all the people responsible for transporting,
installing, commissioning, using, maintaining, repairing or dis-
mantling the machine should consult this manual and read it
carefully before proceeding with the various operations, in order
to avoid any incorrect or inappropriate handling that might be
result in damage to the machine or put people’s safety at risk.
It is just as important that the Manual should always be available
to the operator and it should be kept carefully where the machine
is used ready for easy and immediate consultation in case of any
doubt, or in any case, whenever the need arises.
If after reading the Manual, there are still any doubts concerning
how to use the machine, please do not hesitate to contact the
Manufacturer or approved After Sales Service provider, who is
constantly available to ensure quick and careful service for im-
proved machine operation and optimum eciency.
Note that the safety, hygiene and environmental protection stan-
dards currently applicable in the country where the machine is
installed must always be applied during all phases of machine
operation. Consequently it is the user’s responsibility to ensure
that the machine is operated and used solely under the optimum
safety conditions laid down for people, animals and property.
ATTENTION!!
Machine storage: -25°C to +50°C
Ambient temperature during operation: +4°C to +40°C
This machine is for professional use and must be used by sta trained to use, clean and maintain it, in terms or reliability and safety.
Use the machine in adequately lit premises (See applicable technical standard for the country of use. In Europe, refer to standard
EN 12464-1)
When handling the machine, always check that the parts taken hold of are not mobile elements: risk of dropping and injury to the
lower limbs.
The machine is not designed for use in explosive atmospheres.
The reference language for these instructions is French.
2.2 LOCATION
These are exclusively oor-standing beaters.
To chock or level the beater:
- Remove the foot end piece before adjusting.
- Screw with a screwdriver so that the adjustable pad makes
contact.
- Check it is stable by running the beater at high speed with its
beater. Where necessary, the adjustment can be ne-tuned
with the machine running.
- Ret the plug.
To x the beater to the oor: x using the front feet
- Remove the end pieces from the 2 front feet.
- Use a large screwdriver to extract the adjustable feet.
- Mark the 2 holes to be drilled (Ø8 max. screw, min. length 80,
plugs not supplied).
2.2a
2.2b
2.2a
2.1 DIMENSIONS - WEIGHT (for information only)
A Gross weight when packaged:
B Net weight when equipped (kg)
C Package dimensions (mm) L x w x h
D Overall dimensions of machine: L x w x H (mm)
E Dimensions for tting beater: E x E1 x E2 (mm)
. Handling - Transport
- The beater is delivered xed to a wooden pallet.
- Use a forklift truck to remove it from the pallet, slipping the
forks beneath the feet.
If unloaded manually, take all necessary precautions to
ensure the appliance does not tip at all
2.3 ELECTRICAL CONNECTION
ATTENTION!!
Connection to the electrical power supply must be done according to proper professional practice by a qualied and authorised
person (see current standards and legislation in the country of installation).
If an adapter is used on the socket, a check must be made that the electrical characteristics of this adapter are not lower than
those of the machine.
Do not use multiple plugs
The AC power supply to the machine must comply with the following conditions EN60204-1;
- Maximum voltage variation: ±10%
- Maximum frequency variation: ±1% on a continuous basis, ± 2% over short periods
ATTENTION: the electrical installation must comply (for design, creation and maintenance) with the legal and
standard requirements in the country where used.
- Check that the electric mains voltage, the value shown on the specication plate.
- The machine’s electrical power supply must be protected against voltage surges (short-circuits and excess voltages) using
a circuit breaker compliant with IEC60947-2 properly sized, of the appropriate gauge relative to the place of installation and
machine specications – see the specications shown in column F of gure 2.3a
ATTENTION: Concerning protection against indirect contact (depending on the type of power supply provided and
connection of the exposed conductive parts to the equipotential protection circuit), refer to point 6.3.3 of EN 60204-
1 (IEC 60204-1) with the use of protection devices for automatic shut-o of power in the event of an insulation fault
with a TN or TT, system, or for the IT system, with the use of a permanent insulation or dierentials controller for
automatic shut-o. The requirements of IEC 60364-4-41, 413.1 must apply for this protection.
For example: in a TN or TT system, a dierential circuit breaker must be installed upline of the power supply, with a
suitable power cut-o (e.g.: 30 mA) on the earthing installation for the place where it is planned to install the machine.
ATTENTION: Failure to comply with these instructions means the customer runs the risk of machine failure and/or
accidents due to direct or indirect contacts.
• The electronic beaters run on a single phase power supply.
• A standardised 20A compliant with IEC 60309, 2 pin + earth
wall socket is required as well as a waterproof plug to be mounted
on the power cord.
Note:
The machine can only be used on TN (earthing to
neutral) and TT (earthed neutral) type supplies. Where
a machine has to be installed on an IT (impeding or
isolated neutral) supply, there is a solution which consists
of inserting an isolating transformer and locally putting on
the machine on TN or TT supply.
Must be earthed using the green and yellow wire.
• Warning for the installer:
This electronic whisk is tted with a lter which sends any in-
terference from the mains to earth without going through the
variator. To work properly, the appliance earth connection must
be sound otherwise the interference may go through the variator
and damage it.
NO EARTH = NO PROTECTION = RISK OF BREAKDOWN
XBB20/30 GB 10 2023 2
• Electrical characteristics:
A : Machine
C : Supply voltage
D : Frequency
E : Nominal power
F : Rating of the fuse of the mains cable (Amperes).
• Check the direction of rotation
- Of the planetary gear, anti-clockwise (see arrow on head)
or the tool, clockwise : factory setting.
In the event of a problem, see §5.2 to reverse the direction of
rotation.
2.3a
Use and Safety
- Stop at the end of the time set, or by pressing button C
Note:
- To change the time being counted down, press on button
C A B then change using buttons and ;
- resume cycle by pressing button . D
- The time displayed at the beginning of the cycle remains in
memory
- To permanently interrupt a cycle underway, press button twice.C
b) Continuous operation
- Select ---- on by pressing and holding button E A
- Start by pressing button D
- Stop by pressing button C
c) Speed variation and pre-selected speeds
Speeds I, II and III ( keys) are programmed in the factory. The D
speed can be varied at any time by pressing on keys and F G.
Similarly, the speed can be returned to one of the programmed
settings by pressing on a key.D
• Programming the keysD
- Switch on the power to the appliance
- Start the appliance by pressing button I, II or III depending on
the speed to be programmed
- Adjust the speed using the + and – buttons
- Press and hold the key on the timer until the speed display
goes out.
- Repeat the operation for each speed (I, II, III)
- The programming is deleted when the power to the appliance
is turned o.
3.1
2.3b
3.1 OPERATION - SAFETY
• The safety of the user is guaranteed by:
- The motor halting when the safety guard is opened.
- The design of the guard that allows products to be added
perfectly safely during operation.
- The motor halting when the cradle is lowered. It will not start
again when the ON switch is pressed.
- The need to press the ON button after the machine has been
stopped («no volt release» device)
- Protection against current and power surges, drops in power
and the motor overheating.
- Compliance with the instructions given in this manual for using,
cleaning and maintaining the machine.
• Control panel
A Reduce time setting on timer
B Increase time setting on timer
C STOP button
D START button avec vitesse présélectionnée.
E Timer display
F Increase speed
G Reduce speed
H Speed display
• The beater will start normally when the bowl-holder cradle
assembly is in the working position,
- The safety guard is tted and down,
- The timer is set on continuous or timed operation.
- The bowl is in position on the cradle.
a)Timed operation
- Select time on by pressing buttons and E A B
- Start by pressing button D
Note: The earth values are dened according to the
residual dierential current . Non-compliance with these
instructions may result in invalidation of the warranty.
In certain circumstances depending
on the sensitivity of the protective
cut-outs, it may be necessary to
install SI-type (super immunity) de-
vices to prevent untimely triggering.
To PAT test the Electrolux Range of Food Preparation Equipment,
the PCB board needs to be disconnected before any test is done.
This is due to the fact that the boards are tted with a grounding
diode that can give incorrect result during such a test. Also on a
standard appliance a ash test of 25 amps and up to 3000v is used
but, as you would expect, to use this on equipment, which has a
printed circuit, board would be quite destructive to that board. We
would recommend the use of a PAT tester approved for computer
systems which use a lower rate of amps.
The appliance is perfectly safe and is CE certicated. There are
two ways to get overcome this problem.
· Disconnect the board as instructed and test using test for PC’s,
· Or install the mixer on a fused spur (no plug) as this takes it
away from being a portable appliance and the PAT test is then not
needed.
ATTENTION!!
Clean the machine properly prior to its rst use
Uncontrolled closure of the lid or ram press involves a risk of crushing the ngers.
Never put a hand in the work area while the machine is in operation; risk of injury. It is strictly forbidden
to put the safety systems out of action or modify them: Risk of permanent injury!!!!
Check that the safety devices operate correctly each time before using (see paragraph on «safety system checks»).
Never put a hand, a hard or frozen object in the appliance
For health and safety reasons, always use a strong washable or disposable head covering that covers the hair completely.
XBB20/30 GB 06 20153
Do not use the machine without the bowl.
Product specificaties
| Merk: | Dito Sama |
| Categorie: | Niet gecategoriseerd |
| Model: | 600171 |
Heb je hulp nodig?
Als je hulp nodig hebt met Dito Sama 600171 stel dan hieronder een vraag en andere gebruikers zullen je antwoorden
Handleiding Niet gecategoriseerd Dito Sama
12 Augustus 2025
12 Augustus 2025
12 Augustus 2025
12 Augustus 2025
12 Augustus 2025
12 Augustus 2025
12 Augustus 2025
12 Augustus 2025
12 Augustus 2025
12 Augustus 2025
Handleiding Niet gecategoriseerd
- Becker
- Beam Electronics
- Woonexpress
- Zurn
- Hellberg
- Hilti
- Samlex
- Westinghouse
- Intermec
- Coleman
- CubuSynth
- Metrix
- Verkada
- Baby Trend
- Hamstra
Nieuwste handleidingen voor Niet gecategoriseerd
12 Augustus 2025
12 Augustus 2025
12 Augustus 2025
12 Augustus 2025
12 Augustus 2025
12 Augustus 2025
12 Augustus 2025
12 Augustus 2025
12 Augustus 2025
12 Augustus 2025
