Operating Guide

1 Introduction

AQ435824155085en-000101 / 130R1294 | 1Danfoss A/S © 2023.06

VLT® AutomationDrive FC 360

*M0040301*

This operating guide provides necessary information for qualied personnel to install and commission the

AC drive. Read and follow the instructions to use the drive safely and professionally.

Do not dispose of equipment containing electrical components together with domestic waste.

Collect it separately in accordance with local and currently valid legislation.

Pay particular attention to the safety instructions and general warnings to avoid the risk of death, serious

injury, and equipment or property damage.

2 Safety

WARNING

HIGH VOLTAGE

AC drives contain high voltage when connected to AC mains input.

UNINTENDED START

The motor may start from control panel, I/O inputs, or eldbus at any time, when the drive is connected to the AC mains.

DISCHARGE TIME

The drive contains DC-link capacitors, which can remain charged even when the drive is not powered. High voltage can be

present even when the warning indicator lights are o.

- Stop the motor, and disconnect AC mains, permanent magnet type motors.

- Wait for the capacitors to discharge fully and measure it before performing any service or repair work.

- The minimum waiting time is 20 minutes.

LEAKAGE CURRENT

Leakage currents of the drive exceed 3.5 mA. Make sure that the minimum size of the ground conductor complies with the

local safety regulations for high touch current equipment.

3.1 Mechanical Dimensions

3 Installation

130R1294

90–315 kW, Enclosure Sizes J8–J9

Test method according to IEC 60068-2-43

H

2

S (10 days)

Class 3C3

Aggressive gases (IEC 60721-3-3)

Class Kd

Aggressive environment (IEC 60068-2-43) H

2

S test

Relative humidty

5%–95% (IEC 721-3-3; Class 3K3 (non-condensing) during operation)

0.7 g

Vibration test (standard)

IP20/Chassis

J8–J9 enclosure size

5 Ambient Conditions

4 Specifications

Table 2: Electrical Data for Normal Overload, Mains Supply 3x380–480 V AC

Table 3: Electrical Data for High Overload, Mains Supply 3x380–480 V AC

Drive

Enclosure size

Normal overload=110% current during 60 s

Typical shaft output at 400 V [kW]

Typical shaft output at 460 V [hp]

Output current (3-phase)

Continuous (at 400 V) [A]

Intermittent (60 s overload) (at 400 V) [A]

Continuous (at 460 V) [A]

Intermittent (60 s overload) (at 460 V) [A]

Continuous kVA (at 400 V) [kVA]

Continuous kVA (at 460 V) [kVA]

Maximum input current

Continuous (at 400 V) [A]

Continuous (at 460 V) [A]

Maximum number and size of cables per phase

Mains and motor [mm (AWG)]

Maximum external mains fuses [A]

Estimated power loss at 400 V [W]

Estimated power loss at 460 V [W]

Eciency [%]

Output frequency [Hz]

Heat sink overtemperature trip [°C (°F)]

Control card overtemperature trip [°C (°F)]

Q110Q132Q160Q200Q250Q315

110132160200250315

150200250300350450

212260315395480588

233286347435528647

190240302361443535

209264332397487589

147180218274333407

151191241288353426

204251304381463567

183231291348427516

315

2x95 (2x3/0)2x185 (2x350 mcm)

75 (167)80 (176)

350400550630800

255929543770411651376674

226127243628

98

0–590

110 (230)

356945665714

J8J8J8J9J9J9

Drive

Enclosure size

High overload=150% current during 60 s

Typical shaft output at 400 V [kW]

Typical shaft output at 460 V [hp]

Output current (3-phase)

Continuous (at 400 V) [A]

Intermittent (60 s overload) (at 400 V) [A]

Continuous (at 460 V) [A]

Intermittent (60 s overload) (at 460 V) [A]

Continuous kVA (at 400 V) [kVA]

Continuous kVA (at 460 V) [kVA]

Maximum input current

Continuous (at 400 V) [A]

Continuous (at 460 V) [A]

Maximum number and size of cables per phase

Mains and motor [mm (AWG)]

Maximum external mains fuses [A]

Estimated power loss at 400 V [W]

Estimated power loss at 460 V [W]

Eciency [%]

Output frequency [Hz]

Heat sink overtemperature trip [°C (°F)]

Control card overtemperature trip [°C (°F)]

H90KH110H132H160H200H250

90110132160200250

125150200250300350

177212260315395480

266318390473593720

160190240302361443

240285360453542665

123147180218274333

127151191241288353

171204251304381463

154183231291348427

315

2x95 (2x3/0)2x185 (2x350 mcm)

75 (167)80 (176)

350400550630800

203122892923309340395004

182820512089

98

0–590

110 (230)

287235754458

J8J8J8J9J9J9

Illustration 3: Connecting to Mains, Motor, Control Terminals, and Relays

Illustration 4: Control Terminals

3.3 Connecting to Mains, Motor, Control Terminals, and Relays

3.4 Control Terminals

3.2 Removing the Front Cover

Front viewSide viewBack view

C

b1

B

bD

A

a

E

F

G

D

Illustration 1: Mechanical Dimensions, Enclosure Sizes J8–J9

Table 1: Power Ratings, Dimensions, and Weights for Enclosure Sizes J8–J9

Enclosure size

(IP20)

Enclosure size

(IP20)

J8

J9

J8

J9

Maximum

weight

[kg (lb)]

98 (216)

164 (362)

128 (5.0)

176 (6.9)

495 (19.5)

611 (24.1)

148 (5.8)

EFG

148 (5.8)

Center of gravity [mm (in)]

250 (9.8)

350 (13.8)

180 (7.1)

280 (11.0)

200 (7.9)

Bbb1

271 (10.7)

Width [mm (in)]

889 (35.0)

1096 (43.1)

909 (35.8)

1122 (44.2)

844 (33.2)

AA

(1)

a

1051 (41.4)

Height [mm (in)]

110–160 (150–250)

200–315 (300–450)

3x380–480 V

Power [kW (hp)]

11 (0.4)

11 (0.4)

D

Mounting hole [mm (in)]

375 (14.8)

375 (14.8)

C

Depth [mm (in)]

Procedure:

Step 1: Loosen and remove the 2 screws on the front cover.

Step 2: Disconnect the front cover from the hooks.

RS485 termination switch

(ON=RS485 terminated, OFF=Open)

12

O N

Note: (1) Including decoupling plate.

e30bv154.10

e30bv155.10e30bv159.10e30bv161.10

RELAY 1RELAY 2

010203040506

COMMON

NO

NC

COMMON

NO

NC

VDD1

DI18

DI19

DIO27

DI31

DI32

DI33

GND

DIO29

121819272931323320

10 V

AI53

AI54

AO42

AO45

GND

505354424555

COM RS 485

P RS 485

N RS 485

616869

Illustration 2: Removing the Front Cover

Step 1Step 2

Screws

Hooks

Mains

Motor

Ground

Control

terminals

Relays
