Pagina 1/12
Run reliably at full
load for ambient
temperatures up to
50
°C
Comparison of features and specifications for
iC2-Micro VLT® Micro Drive FC 51 and
drives.danfoss.com
Brochure | iC2-Micro & VLT® Micro Drive FC 51
Danfoss Drives · AD423936930805en-0005012
Contents
General comparison of iC2-Micro and VLT® Micro Drive FC 51
................................. 3
Model code and type code comparison
............................................................................... 4
Product models comparison
......................................................................................................... 5
Comparison of dimensions and mounting clearance
.................................................... 6
Comparison of terminals
.................................................................................................................. 8
For your convenience in selecting and retrofitting drives, we provide some key comparative
features and specifications of the iC2-Micro and VLT® Micro Drive FC 51.
iC2-Micro VLT® Micro Drive FC 51
3Danfoss Drives · AD423936930805en-000501
General comparison
of iC2-Micro and VLT® Micro Drive FC 51
Key specifications
Attribute
iC2-Micro VLT® Micro Drive FC 51
3-phase 380-480 V
0.37 – 22 kW 0.37 – 22 kW
1-phase 200-240 V
0.37 – 2.2 kW 0.18 – 2.2 kW
3-phase 200-240 V
0.37 – 11 kW 0.25 – 3.7 kW
1-phase 100-120 V
0.37 – 1.1 kW N.A.
Enclosure
IP20/Open type IP20/Open type
Motor type
IM, PM (SPM & IPM) Only IM
Motor identification
Automatic Motor Adaptation (AMA) Automatic Motor Tuning (AMT)
Output frequency
Induction motor
• 0-200 Hz (VVC+ mode)
• 0-500 Hz (U/f mode)
PM motor
• 0-400 Hz (VVC+ mode)
Induction motor
• 0-200 Hz (VVC+ mode)
• 0-400 Hz (U/f mode)
Ramp time
0.01-3600 sec 0.05-3600 sec
Overload capacity
150% for 1 minute 150% for 1 minute
Overload torque at start
200%/1s N.A.
Maximum motor cable length (unshielded)
75 m (246 ft) 50 m (164 ft)
EMC filter
Two versions:
• Built-in EMC filter
• Without built-in EMC filter
Built-in EMC filter
Cooling fan
Replaceable fan with fan on/off control Fixed fan without fan control
Ambient temperature
50 °C (122 °F) at full load
Max. 55 °C (131 °F) with derating
40 °C (104 °F) at full load
Max. 50 °C (122 °F) with derating
Natural cooling
Frame size MA01c N.A.
HMI
Built-in control panel with potentiometer
as default.
Control Panel 2.0 OP2 as external control
panel option:
• Multi-language texts display
• Easy for commissioning
• Parameters setting and copy
• Support two kinds of cabinet mounting kit
For control panel details, refer to
the Application Guide
Detachable numerical control panel as option:
• VLT® Control Panel LCP 11
without potentiometer
• VLT® Control Panel LCP12
with potentiometer
For control panel details, refer to
the Programming Guide
PC tool
MyDrive® Insight VLT® Motion Control Tool MCT 10
Off-line configuration
With adapter option, support off-line configuration N.A.
Torque control
Torque open loop control N.A.
Process controller
PID controller PI controller
Logical control
Smart Logic Controller (SLC) Smart Logic Controller (SLC)
RS485 port baud rate
Max. 115,000 baud communication speed Max. 38,400 baud communication speed
Extra RJ45 port
RS485 based, and used for connecting external
control panel and PC tool.
N.A.
Safety standards
EN/IEC 61800-5-1, UL 61800-5-1 EN/IEC 61800-5-1, UL 508C
UL LZGH2/8 certification
Certified in accordance with UL/IEC 60335-2-40
and CSA C22.2 No.0335-2-40
N.A.
New features
• Kinetic backup
• Clockwise direction
• Latch start reverse
• Input phase loss trip
• Setting wizard with application selections
• Dead zone control
• Sleep mode function
N.A.
