SPECIFICATION SHEET

32F 99045362J

MODEL AE80B

FLEX

TM

SERIES FAN

DESCRIPTION

BLOWER:

• Plug-in, permanently lubricated motor - engineered for

continuous operation

• Dynamically balanced centrifugal blower wheel for quiet,

efficient performance

• Low RPM for quiet operation

HOUSING:

• Rugged, 26 gauge, galvanized steel construction

• Polymeric, 4” duct connector with tapered sleeve and no

metallic clatter

• 5¾” height allows for 2” x 6” ceiling installations

• Sturdy, easy, four-point mounting directly to joist

• Can be mounted in ceilings up to 7/12 pitch

• Can be installed in a wall if mounted 8-ft. or more above

the floor

GRILLE:

• Polymeric construction

• Innovative design - the result of extensive research with

designers and consumers

CONTROLS (Purchase separately):

• Refer to Broan’s catalog for a complete line of

accessories to effectively adapt these fans to your

construction requirements.

U.L. Listed for use over bathtubs and showers when

connected to a GFCI protected branch circuit (ceiling

mount only).

3-Year Warranty

NOTE: Model AE80B available as housing pack

Model A000HFNF or A000HFKT - plus finish pack

Model AE80BF1.

TYPICAL SPECIFICATION

Fan shall be Broan Model AE80B.

Fan shall have corrosion resistant galvanized steel housing

with four-point mounting capability. It shall be ducted to a

roof or wall cap using 4” round ductwork.

Blower assembly shall be removable, have a centrifugal-

type blower wheel and a permanently lubricated motor

designed for continuous operation.

Non-metallic damper/duct connector shall be included.

Air delivery shall be no less than the airflow values and

no greater than the sound level values listed in the HVI

Performance Specifications provided in this specification

(see following chart). All air and sound ratings shall be

certified by HVI.

Ceiling Ventilator shall be U.L. Listed for use over bathtubs

and showers when connected to a GFCI protected branch

circuit.
