HEX31WPB-TX QUICK REFERENCE GUIDE

01Contact: support@blustream.com.au | support@blustream-us.com | support@blustream.co.uk

HEX31WPB-TX

Quick Reference Guide

Our HEX31WPB-TX HDMI / USB-C wall plate HDBaseT™ Transmitter is a multi-

format 4K input switcher solution delivering HDMI and USB-C inputs up to 70m

at 1080p (40m at 4K 60Hz 4:2:0). The HEX31WPB-TX features both manual or

automated source selection and includes display on / o control via CEC, RS-232

and IR (via compatible HDBaseT™ receiver / matrix). The HEX31WPB-TX has been

designed to work with all Blustream HDBaseT™ receiver and matrix solutions, be

installed in both UK and European backboxes, and can be powered locally or from

compatible Blustream HDBaseT™ products.

Introduction

FEATURES:

• Features 2 x HDMI & 1 x USB-C inputs with manual / auto source selection

• Advanced HDBaseT™ technology oering distribution of video and audio over a single CAT cable

• Supports 4K UHD video up to 40m (3840 x 2160 @30Hz 4:4:4, 4096 x 2160 @24Hz 4:4:4, and 4K @60Hz 4:2:0)

• Extends HDMI at 1080p up to a distance of 70m

• Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and DTS-HD

Master Audio transmission

• Manual input selection via front panel and RS-232

• Programmable ON / OFF button utilising IR, RS-232 or CEC for control of display device at HDBaseT™ receiver

• Supports 12V-48V PoC from compatible Blustream HDBaseT™ receiver / matrix products

• Bi-directional RS-232 pass through

• Supports IR pass-through to HDBaseT™ device

• Compatible with all Blustream HDBaseT™ receiver / matrix products*

• Magnetic faceplate surround allowing both UK & EU backbox compatibility

• HDCP 2.2 support

*Technical performance is subject to the features supported on the connected HDBaseT™ device
