Description

Our HEX31WPW-TX HDMI/USB-C wall plate HDBaseT™ Transmitter is

a multi-format 4K input switcher solution delivering HDMI and USB-C

inputs up to 70m at 1080p (40m 4K 60Hz 4:2:0).

The HEX31WPW-TX features both manual or automated source

selection and includes display on / o control via CEC, RS-232 and IR

(via compatible HDBaseT™ receivers / Matrix).

The HEX31WPW-TX has been designed to work with all Blustream

HDBaseT™ receiver and matrix solutions, be installed in both UK and

European back boxes and can be powered locally or from compatible

Blustream HDBaseT™ products.

HEX31WPW-TX







2 x HDMI & 1 USB-C Wall Plate HDBaseT

TM

Transmitter

Blustream cannot be held responsible for errors in typography or photography. Specications are subject to change without notice.

89mm

105mm

Key Features

•

Features 2 x HDMI & 1x USB-C inputs with manual / auto source

selection

• Advanced HDBaseT™ technology oering distribution of video

and audio over a single CAT cable

• Supports 4K UHD video up to 40m (3840 x 2160 @30Hz 4:4:4,

4096 x 2160 @24Hz 4:4:4, and 4K @60Hz 4:2:0)

• Extends HDMI at 1080p up to a distance of 70m

• Supports all known HDMI audio formats including Dolby TrueHD,

Dolby Atmos, Dolby Digital Plus and DTS-HD Master Audio

transmission

• Input selection via front panel, IR or RS-232

• Programmable ON / OFF button utilising IR, RS-232 or CEC for

control of display device at HDBaseT™ receiver

• Supports 12V-48V PoC from compatible Blustream HDBaseT™

receiver / matrix products

• Bi-directional RS-232 pass through

• Supports IR pass-through to HDBaseT™ device

• Compatible with all Blustream HDBaseT™ receiver / matrix

products *

• Magnetic faceplate surround allowing both UK & EU back box

compatibility

• HDCP 2.2 support

* Technical performance is subject to the features supported on the connected

HDBaseT™ device

** Please note: The USB-C input port on this unit does not provide PD charging

to devices connected for video distribution.
