HEX11WP-TX QUICK REFERENCE GUIDE

Contact: support@blustream.com.au | support@blustream-us.com | support@blustream.co.uk

HEX11WP-TX

Quick Reference Guide

01

Our HEX11WP HDMI Wall Plate HDBaseT™ Transmitter is a 4K solution that extends

HDMI up to 70m at 1080p (40m at 4K 60Hz 4:2:0). The HEX11WP-TX has been

designed to work with all Blustream HDBaseT™ receiver and matrix solutions, be

installed in both UK and European backboxes and can be powered locally or from

compatible Blustream HDBaseT™ products.

Introduction

FEATURES:

• Advanced HDBaseT™ technology oering distribution of video and audio over a single CAT cable

• Supports 4K UHD video up to 40m (3840 x 2160 @30Hz 4:4:4, 4096 x 2160 @24Hz 4:4:4, and 4K @60Hz 4:2:0)

• Extends HDMI at 1080p up to a distance of 70m

• Smart EDID function automatically limits EDID to within HDBaseT™ specification to improve compatibility

#

• Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and DTS-HD

Master Audio transmission

• Supports 12V-48V PoC from compatible Blustream HDBaseT™ receiver / matrix products

• Bi-directional RS-232 pass-through

• Supports IR pass-through to HDBaseT™ device

• Compatible with all Blustream HDBaseT™ receiver / matrix products*

• Magnetic faceplate surround allowing both UK & EU backbox compatibility

• HDCP 2.2 support

*Technical performance is subject to the features supported on the connected HDBaseT™ device.

#

EDID function added to products from Revision B onward.
