SAVE FOR FUTURE USE

7302354-100 Rev. A 4/18

Product names listed herein are trademarks of AS America, Inc.

© AS America, Inc. 2018

INSTALLATION INSTRUCTIONS

CARE AND MAINTENANCE

CAUTION: PRODUCT IS FRAGILE. TO AVOID BREAKAGE AND POSSIBLE INJURY HANDLE WITH CARE!

!

NOTE: Pictures may not exactly define contour of china and components.

Thank you for selecting American Standard - the benchmark of fine quality for over 100 years. To ensure this product is installed

properly, please read these instructions carefully before you begin. (Certain installations may require professional help.) Also be

sure your installation conforms to local codes.

Water Supply Line

EZ-INSTALL KIT INCLUDED WITH TANK

4216.228 LEFT HAND TANK / 4216.823 RIGHT HAND TANK

BOWL 3271.101 RIGHT HEIGHT

®

ELONGATED

SOLD SEPARATELY

EZ-INSTALL KIT INCLUDED WITH BOWL

TOWN SQUARE

®

S

1.28 gpf / 4.8 Lpf 2-piece Toilet

Wax Ring

T-Bolts with

Retainer (2)

Bowl-To-Floor

Knobs (2)

Tank To Bowl

Gasket

Metallic (Brass)

Tank Nuts (2)

Plastic

Coupling Nut (1)

Coupling

Washer (1)

Attachment

Handle

Bolt Caps (2)

Toilet Seat

BEFORE INSTALLING YOUR TOILET: please see your product spec page to verify the dimensions and water supply connections.

Visit our website where you can search by Model number for the product spec page at: http://www.americanstandard-us.com/
