U.S. Patent No. D403,750
Certified to comply with ANSI A112.18.1
Installation
Instructions
TM
T480.508
T480.507
1/2" NPT
7" REF.
FINISHED WALL
BOTTOM OF TUB
74" FOR HEAD
CLEARANCE
4" REF.
5-1/8" REF.
OPTIONAL TO FINISHED
FLOOR USUALLY
BETWEEN 65'' AND 78''
TOP OF TUB RIM
1/2" COPPER
1-5/8" TO 3-1/4"
4" REF.
7-5/8" REF.
ROUGHING-IN DIMENSIONS
FOR REFERENCE ONLY
M968698 REV. 1.1
BATH AND SHOWER TRIM KITS
Thank you for selecting American-Standard...the benchmark
of fine quality for over 100 years.
To ensure that your installation proceeds smoothly--
please read these instructions carefully before you begin.
Teflon Tape
Flat Blade Screwdriver
Plumbers' Putty or Caulking
Phillips Screwdriver
Adjustable Wrench
RECOMMENDED TOOLS
OBSOLETE
