Pagina 1/10
American DJ®
4295 Charter Street
Los Angeles CA. 90058
www.americandj.com
7/05
User Instructions
Unpacking: Thank you for purchasing the Performance Scan 250™
by American DJ®. Every Performance Scan 250™ has been thoroughly
tested and has been shipped in perfect operating condition. Carefully
check the shipping carton for damage that may have occurred during
shipping. If the carton appears to be damaged, carefully inspect your
fixture for any damage and be sure all equipment necessary to oper-
ate the unit has arrived intact. In the event damage has been found
or parts are missing, please contact our toll free customer support
number for further instructions. Please do not return this unit to your
dealer without first contacting customer support.
Introduction: The Performance Scan 250™ is a six channel DMX
intelligent scanner that uses 11 colors, 7 rotating gobo patterns,
(seperate wheels) and a 250w lamp to create a bright and colorful light
show. This unit can also run as a stand alone, sound-active unit, or
in a Master/Slave configuration. The Performance Scan 250
™
comes
with several built in programs and is best used in multiples of four. For
best results use fog or special effects smoke to enhance the beams
projections.
Customer Support: American DJ provides a toll free customer ®
support line, to provide help and to answer any question should you
encounter problems during your set up or initial operation. You may
also visit us on the web at www.americandj.com for any comments or
suggestions. Service Hours are Monday through Friday 9:00 a.m. to
5:00 p.m. Pacific Standard Time.
Voice: (800) 322-6337
Fax: (323) 582-2610
E-mail: support@americandj.com
Warning! To prevent or reduce the risk of electrical shock or fire, do
not expose this unit to rain or moisture.
Caution! There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures war-
ranty. In the unlikely event your unit may require service please contact
American DJ®.
Performance Scan 250™ General Information
American DJ - www.americandj.com - Performance Scan 250™ Instruction Manual Page 2®
Intelligent Scanner
Performance
American DJ - www.americandj.com - Performance Scan 250™ Instruction Manual Page 3®
• Micro-Stepping Motors for Smooth Color and Gobo Transitions
• DMX-512 Protocol Compatible (Uses four DMX Channels)
• Selectable 110v/60Hz or 230v/50Hz
• 6 Rotating Gobo Patterns Plus Spot
• 9 Colors Plus White
• Master/Slave Operation
• Internal Microphone
• Variable Speed Strobe Function
• Gobo Shake
• LED Display Menu
• ZB-EHJ5 24v/250w Long Life Lamp
• 1 Year Warranty
Performance Scan 250™ Features
The Performance Scan 250™ carries a one year limited warranty.
Please fill out the enclosed warranty card to validate your purchase.
All returned service items whether under warranty or not, must be
freight pre-paid and accompany a return authorization (R.A.) number.
The R.A. number must be clearly written on the outside of the return
package. A brief description of the problem as well as the R.A. num
-
ber must also be written down on a piece of paper included in the
shipping carton. If the unit is under warranty, you must provide a copy
of your proof of purchase invoice. You may obtain a R.A. number by
contacting our customer support team on our toll free customer sup
-
port number. All packages returned to the service department not dis
-
playing a R.A. number on the outside of the package will be returned
to the shipper.
Performance Scan 250™ Product Registration
American DJ - www.americandj.com - Performance Scan 250™ Instruction Manual Page 4®
To optimize the performance of this product, please read these operating
instructions carefully to familiarize yourself with the basic operations of
this unit. These instructions contain important safety information regard-
ing the use and maintenance of this unit. Please keep this manual with
the unit, for future reference.
Performance Scan 250™ General Instructions
• To reduce the risk of electrical shock or fire, do not expose this unit
rain or moisture
• Do not spill water or other liquids into or on to your unit.
• Be sure that the local power outlet match that of the required volt-
age for your unit.
• Do not attempt to operate this unit if the power cord has been
frayed or broken.
• Do not attempt to remove or break off the ground prong from
the electrical cord. This prong is used to reduce the risk of electrical
shock and fire in case of an internal short.
• Disconnect from main power before making any type of connection.
• Do not remove the cover under any conditions. There are no user
serviceable parts inside.
• Never operate this unit when it’s cover is removed.
• Never plug this unit in to a dimmer pack
• Always be sure to mount this unit in an area that will allow proper
ventilation. Allow about 6” (15cm) between this device and a wall.
• Do not attempt to operate this unit, if it becomes damaged.
• This unit is intended for indoor use only, use of this product out-
doors voids all warranties.
• During long periods of non-use, disconnect the unit’s main power.
• Always mount this unit in safe and stable matter.
• Power-supply cords should be routed so that they are not likely to
be walked on or pinched by items placed upon or against them,
paying particular attention to cords at plugs, convenience recep-
tacles, and the point where they exit from the appliance.
• Cleaning -The fixture should be cleaned only as recommended by
the manufacturer. See page 16 for cleaning details.
• Heat -The appliance should be situated away from heat sources
such as radiators, heat registers, stoves, or other appliances
(including amplifiers) that produce heat.
• The fixture should be serviced by qualified service personnel when:
A. The power-supply cord or the plug has been damaged.
B. Objects have fallen, or liquid has been spilled into the appliance.
C. The appliance has been exposed to rain or water.
D. The appliance does not appear to operate normally or exhibits a
marked change in performance.
Performance Scan 250™ Safety Precautions
American DJ - www.americandj.com - Performance Scan 250™ Instruction Manual Page 6American DJ - www.americandj.com - Performance Scan 250™ Instruction Manual Page 5 ®®
Performance Scan 250™ Controls and Functions
TOP
1. Breaker - A 5A built-in safety breaker to reduce the risk of electrical
shock or fire and protect the circuitry. In the case of a internal short or
power surge.
2. Power Cord Inlet - This unit is equipped with a removable I.E.C.
power cord. Be sure to only use the power cord included with the
unit, this cord is designed to match the electrical requirements of the
unit. Other cords may cause the unit to overheat or malfunction. Volt-
age may vary from venue to venue, when connecting this unit to a
power supply be sure to connect to a matching power outlet. Never
use this fixture if the ground prong has been removed or broken off.
The ground prong is designed to reduce the risk of fire or electrical
shock in the event the unit suffers from an internal short.
3. XLR Input Jack - This jack is used to accept an incoming DMX
signal or Master/Slave signal.
4. XLR Output Jack - This jack is used to transmit the incoming
DMX signal to another DMX fixture, or transmit a Master/Slave signal
to the next Performance Scan 250™ in the chain. For best results in
DMX or Master/Slave mode terminate this jack if it is the last unit in the
chain. See “Terminator” on page 8.
LED
1. Digital Display - This display shows the menu and operating func-
tions.
2. Enter Button -
This button is used confirm a function when working
in the system menu.
3. Down Button
- This button is used to scroll backwards when navi-
gating through the system menu.
4. Up Button
- This button is used to scroll forward when navigating
through the system menu.
5. No Button
- This button is used to deselect a function.
6. Yes Button
- This button is used to select a function.
NODOWN UPENTER
YES
Control board
1 65432
Performance Scan 250™ Digital Display
1
3
4
2
