American Audio Active DBM Handleiding

Bekijk gratis de handleiding van American Audio Active DBM (2 pagina’s), behorend tot de categorie Niet gecategoriseerd. Deze gids werd als nuttig beoordeeld door 10 mensen en kreeg gemiddeld 4.6 sterren uit 5 reviews. Heb je een vraag over American Audio Active DBM of wil je andere gebruikers van dit product iets vragen? Stel een vraag

©American Audio® - www.AmericanAudio.us-

LOS ANGELES, CA. 90040

Model:Active DBM

SPECIFICATIONS:

Power Consumption: 10W

Power: 12V DC 500mA

Weight: 1.75 lbs. / 0.85

Size: 1 3/4” (L) x 19” (W) x 1 3/4” (H)

19 in. single space rack mount.

Thank you for purchasing this ©American Audio® product. For your convenience this products

ready to be used, there is no assembly required. Please read the following instructions before

installing or using your new unit.

Operating Instructions:

1. Plug in proper AC adapter.

2. Connect music signal to Left and Right input jacks, must be pre-amp level.

3. Turn the power switch on.

4. Adjust L and R audio controls to desired response

5. This unit has BAR and DOT display modes.

BAR mode: Set switch to BAR position, LEDs will glow from -57dB to 0dB according to signal

strength.

DOT mode: Set Mode switch to DOT position, only two LEDs glow and chase from left to right

according to audio level variety.

Sensitivity Adjustment: For low level and high level signals, adjust accordingly.

NOTE: This is not a Line Transformer, do not plug an RCA (unbalanced source) and then use XLR

outs or vice versa.

User Instructions

Active DBM
