Pagina 1/4
American DJ
4295 Charter Street
Los Angeles CA. 90058
www.americandj.com
2/06
User Instructions
Unpacking: Thank you for purchasing the Spektra 250™ by Ameri-
can DJ . Every Spektra 250™ has been thoroughly tested and has ®
been shipped in perfect operating condition. Carefully check the ship-
ping carton for damage that may have occurred during shipping. If the
carton appears to be damaged, carefully inspect your fixture for any
damage and be sure all equipment necessary to operate the unit has
arrived intact. In the event damage has been found or parts are miss-
ing, please contact our toll free customer support number for further
instructions. Do not return this unit to your dealer without first contact-
ing customer support.
Introduction: This unit uses 11 pieces of individual textured glass
mounted on a wheel, a colored dichoic dish, and 10 colored tiles to pro-
duce vibrant colors and extravagant gobo patterns. The Spektra 250™
is a stand alone sound active piece.
Customer Support: American DJ provides a toll free customer sup-®
port line, to provide set up help and to answer any question should you
encounter problems during your set up or initial operation. You may
also visit us on the web at www.americandj.com for any comments or
suggestions. Service Hours are Monday through Friday 9:00 a.m. to
5:00 p.m. Pacific Standard Time.
Voice: (800) 322-6337
Fax: (323) 582-2610
E-mail: support@americandj.com
To purchase parts online visit http://parts.americandj.com
Warning! To prevent or reduce the risk of electrical shock or fire, do
not expose this unit to rain or moisture.
Caution! There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures war-
ranty. In the unlikely event your unit may require service please contact
American DJ .®
Spektra 250™ General Information
© ®American DJ - www.americandj.com - Spektra 250™ Instruction Manual Page 2
© ®American DJ - www.americandj.com - Spektra 250™ Instruction Manual Page 3
• ELC10 24v/250w Lamp
• 11 Textured Glass Gobos, and 10 Colors
• Fan Cooled.
Spektra 250™ Main Features
The Spektra 250™ carries a one year (365 days) limited warranty.
Please fill out the enclosed warranty card to validate your purchase.
All returned service items whether under warranty or not, must be
freight pre-paid and accompany a return authorization (R.A.)
number.
If the unit is under warranty, you must provide a copy of your proof of
purchase invoice. Please contact American DJ
® customer support for
a R.A. number.
Spektra 250™ Product Registration
• To reduce the risk of electrical shock or fire, do not expose this unit
rain or moisture
• Do not spill water or other liquids into or on to your unit.
• Be sure that the local power outlet match that of the required volt-
age for your unit.
• Do not attempt to operate this unit if the power cord has been
frayed or broken.
• Do not attempt to remove or break off the ground prong from
the electrical cord. This prong is used to reduce the risk of electri-
cal shock and fire in case of an internal short.
• Disconnect from main power before making any type of connection.
• Do not remove the cover under any conditions. There are no user
serviceable parts inside.
• Never operate this unit when it’s cover is removed.
• Never plug this unit in to a dimmer pack
• Always be sure to mount this unit in an area that will allow proper
ventilation. Allow about 6” (15cm) between this device and a wall.
• Do not attempt to operate this unit, if it becomes damaged.
• This unit is intended for indoor use only, use of this product out-
doors voids all warranties.
• During long periods of non-use, disconnect the unit’s main power.
• Always mount this unit in safe and stable matter.
• Power-supply cords should be routed so that they are not likely to
be walked on or pinched by items placed upon or against them,
paying particular attention to cords at plugs, convenience recep-
tacles, and the point where they exit from the appliance.
• Cleaning -The fixture should be cleaned only as recommended by
the manufacturer. See page 3 for cleaning details.
• Heat -The appliance should be situated away from heat soures
such as radiators, heat registers, stoves, or other appliances (incl-
uding amplifiers) that produce heat.
• The fixture should be serviced by qualified service personnel
when:
A. The power-supply cord or the plug has been damaged.
B. Objects have fallen, or liquid has been spilled into the appliance.
C. The appliance has been exposed to rain or water.
D. The appliance does not appear to operate normally or exhibits a
marked change in performance.
Spektra 250™ Safety Precautions
© ®American DJ - www.americandj.com - Spektra 250™ Instruction Manual Page 4
Spektra 250™ Cleaning
Fixture Cleaning: Due to fog residue, smoke, and dust cleaning the
internal and external optical lenses and mirror should be carried out
periodically to optimize light output. Cleaning frequency depends on
the environment in which the fixture operates (I.e. smoke, fog residue,
dust, dew). In heavy club use we recommend cleaning on a monthly
basis. Periodic cleaning will ensure longevity, and crisp output.
1. Use normal glass cleaner and a soft cloth to wipe down the out-
side casing.
2. Use a brush to wipe down the cooling vents and fan grill.
3. Clean the external optics and mirror with glass cleaner and a soft
cloth every 20 days.
4. Clean the internal optics with glass cleaner and a soft cloth every
30-60 days.
5. Always be sure to dry all parts completely before plugging the unit
back in.
Power Supply: Before plugging your unit in, be sure the source
voltage in your area matches the required voltage for your American
DJ Spektra 250™ before attempting operation. ®
General Operation: Just plug this light in, and watch it go. This
fixture is designed to operate as a stand alone unit. It has been tested
and the lamp has been installed at the factory, there is no assembly
necessary. The Spektra 250™ is ready to be plugged in, out of the
box, there is no power switch. If there is no lamp output check the
breaker and bulb. If the breaker and bulb are good, please return the
unit for servicing.
Operating Modes:
This unit comes with two 3-way multi-operating switches located on
the rear of the unit. The switches each have three (3) different operat-
ing modes.
The top Switch will control the textured glass wheel.
Switch in the "I" position: Mode 1 - In this mode the textured glass
wheel will spin continuously, regardless of the presence of sound.
Switch in the “0” position: Mode 2 - In this mode the textured glass
wheel will remain static.
Switch in the “II” position: Mode 3 - In the this mode the textured
glass wheel will only rotate in the prescence of sound. Please note
that tapping on the unit, or high pitched sounds may not trigger the
unit, the unit is designed to react to low frequencies (bass). Also note
that the music sensitivity is preset at the factory and may not be
changed or adjusted.
The bottom switch will control the Color Arm.
Switch in the "I" position: Mode 1 - In this mode the color arm
will
move continuously, regardless of the presence of sound.
Switch in the “0” position: Mode 2 - In this mode the color arm will
remain static.
Switch in the “II” position: Mode 3 - In the this mode the color arm
will only move in the prescence of sound.
Spektra 250™ Operation
© ®American DJ - www.americandj.com - Spektra 250™ Instruction Manual Page 6© ®American DJ - www.americandj.com - Spektra 250™ Instruction Manual Page 5
Spektra 250™ Lamp Replacement
Caution: Always replace with the exact same type lamp, unless oth-
erwise specified by an authorized American DJ
® technician. Replace
with anything other than the specified part can damage your unit and
will void your manufactures warranty.
Warning: If you continue to blow either the lamp or the breaker,
STOP using the unit. Contact customer support for further instruc
-
tions, you may have to return the unit for servicing. Continuing to use
the unit may cause serious damage.
Breaker Reset: This unit is equipped with a built-in safety breaker.
This breaker is designed to close the power circuit in the event of an
internal short or power surge. This will reduce the risk of electrical
shock or fire and protect the circuitry. To reset the breaker, push the
breaker button in until you hear it “pop” back in to place. If the break
-
er continues to pop, stop using the unit and contact our customer
support team, the unit may need to be returned for service
.
Lamp Replacement: Caution! Never attempt to change the lamp
while the fixture is plugged in. Always disconnect the main power
and allow the unit ample time to cool before attempting to replace the
lamp. Lamp replacement has been made simple by incorporating the
use of a flip-up front cover that is retained by a thumb screw.
1. Be sure to follow the proper handling procedures that deal with
halogen lamps.
2. Remove the thumb screw on the top front of the unit.
3. After removing the thumb screw, pull off socket assembly protec-
tive cover.
4. Carefully remove the old lamp and discard it in the trash.
5. Replace the lamp with an exact match and reassemble in reverse
order.
Halogen Lamp Warning: This fixture is fitted
with halogen lamps which are highly susceptible
to damage if improperly handled. Never touch the
lamps with your bare fingers as the oil from your
hands will shorten lamp life. Also, never move the
fixture until the lamps have had ample time to cool.
Remember, lamps are not covered under warranty
conditions.
