User Instructions
Rev. 10/09
American DJ®
Fusion Scan 250™ Introduction
© ®American DJ Supply - www.americandj.com - Fusion Scan 250™ User Manual Page 2
Introduction: Congratulations and thank you for purchasing the Fusion
Scan 250™ by American DJ , one of the finest pieces of its kind on the ®
market today! The Fusion Scan 250™ is a excellent, light weight, intel-
ligent fixture. Due to it’s physical specifications, it’s a great piece for
mobile DJ’s, roller rinks, small clubs, bars, and bowling centers. When
used in multiples of two or more, these units create an effect that rivals
that of units that can cost up to three times the price. The Fusion Scan
250™ was designed to run in a Master/Slave mode but can be used
with any universal DMX-512 controller.
Customer Support: American DJ provides a toll free customer sup-®
port line, to provide set-up and installation help and to answer any
question should you encounter problems during your set up or initial
operation. You may also visit us on the web at www.americandj.com
for any comments or suggestions. Toll free customer service hours are
Monday through Friday 9:00 a.m. to 5:30 p.m. Pacic Standard Time.
Voice: (800) 322-6337
Fax: (323) 582-2941
E-mail: support@americandj.com
To purchase parts online visit http://parts.americandj.com
Warning! To prevent or reduce the risk of electrical shock or re, do
not expose this unit to rain or moisture.
Caution! There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures war-
ranty. In the unlikely event your unit may require service please contact
American DJ customer support.®
Please recycle the shipping carton when ever possible.
Improvements and changes in specications and design to this
manual and unit may be made at any time without prior notice.
HALOGEN LAMP WARNING!
This fixture is fitted with a halogen lamp which is highly susceptible to
damage if improperly handled. Never touch the lamp with your bare
fingers as the oil from your hands will shorten the lamp life. Never
install, mount, or place this fixture in areas prone to heavy vibration.
Also, never move the fixture until the lamp has had ample time to
cool. Remember, lamps are not covered under warranty conditions.
© ®American DJ Supply - www.americandj.com - Fusion Scan 250™ User Manual Page 3
• Do not spill water or other liquids into or on to your unit.
• Be sure that the local power outlet match that of the required volt
age for your unit.
• Do not attempt to operate this unit if the power cord has been
frayed or broken. Please route your power cord out of the way of
foot trafc.
• Do not attempt to remove or break off the ground prong from
the electrical cord. This prong is used to reduce the risk of electrical
shock and re in case of an internal short.
• Disconnect from main power before making any type of connection.
• Do not remove the top cover under any conditions. There are no
user serviceable parts inside.
• Never plug this unit in to a dimmer pack
• Always be sure to mount this unit in an area that will allow proper
ventilation. Allow about 6” (15cm) between this device and a wall.
• Do not attempt to operate this unit, if it becomes damaged in any
way.
• Never operate this unit when it’s cover is removed.
• To reduce the risk of electrical shock or re, do not expose this unit
rain or moisture
• This unit is intended for indoor use only, use of this product out
doors voids all warranties.
• During long periods of non-use, disconnect the unit’s main power.
• Always mount this unit in safe and stable matter.
• Power Cord Protection - Power cords should be routed so they are
not likely to be walked on or pinched by items placed upon or
against them, paying particular attention to cords at plugs, conve-
nience receptacles, and the point where they exit from the unit.
• Cleaning - Follow the directions on page 14.
• Heat -The unit should be situated away from heat sources such
as radiators, heat registers, stoves, or other appliances (including
amplifiers) that produce heat.
Fusion Scan 250™ Safety Precautions
DANGER
VISIBLE LASER RADIATION
-AVOID DIRECT EYE EXPOSURE
LASER DIODE
WAVELENGTH : 635~650 nm
Max Output : <4.9mW
Class IIIa Laser Product
!
!
© ®American DJ Supply - www.americandj.com - Fusion Scan 250™ User Manual Page 4
Fusion Scan 250™ Safety Precautions
• The fixture should be serviced by qualified service personnel when:
A. The power-supply cord or the plug has been damaged.
B. Objects have fallen, or liquid has been spilled into the appliance.
C. The appliance has been exposed to rain or water.
D. The fixture does not appear to operate normally or exhibits a
marked change in performance.
The Fusion Scan 250™ features a bright 250 watt halogen bulb with
a separate gobo and color wheel and a green laser effect. The color
wheel features seven brilliant colors plus white and the gobo wheel
features 10 gobos plus a large spot. This fixture incorporates the
use of high quality stepper motors for a more accurate mirror move-
ment. Mirror movement allows for a full 90 degree tilt (vertical) and a
45 degree pan (horizontal). An internal built in microphone allows the
fixtures to run in Stand Alone mode so there is no need for an exter-
nal controller. The Fusion Scan 250™ may also be set-up to run in a
Master-Slave mode when used in multiples, up to four units. When
used in the Master-Slave mode, the unit will chase to several internal
programs. The Fusion Scan 250™ can also be controlled via a stan-
dard DMX controller such as the Elation Show Designer,™ or the ®
Elation DMX Operator,™ giving the user independent control over the ®
gobo and color wheel as well as the mirrors pan and tilt movements.
Note: The built in programs in the Fusion Scan 250™ are so good you
may never need a DMX controller.
• ZB-ELC10 24V/250W
• DMX-512 Compatible.
• Stepper motors for smooth movements.
• 7 colors plus white.
• 10 Gobos plus spot.
• Green Laser
• Gobo Shake
• Master/Slave Operation
• Sound Active.
• Optional MINI/C controller, for blackout control.
• Optional Wireless MINI/C controller, for blackout control.
Fusion Scan 250™ Features
© ®American DJ Supply - www.americandj.com - Fusion Scan 250™ User Manual Page 5
Fusion Scan 250™ Laser Warnings and Safety
NON-INTERLOCKED HOUSING WARNING
The Fusion Scan 250™ contains high power laser devices internally.
Do not open the laser housing, due to the potential exposure to
unsafe levels of laser radiation. The laser power levels, if the unit is
opened, can cause instant blindness, skin burns and res.
STOP AND READ ALL LASER SAFETY DATA
OPERATION INSTRUCTIONS AND LASER SAFETY
The light source emitted from this product can potentially cause eye
injury if not set up and used properly. The light source emitted from a
laser is very different from any other light sources with which you may
be aware of. Laser light is thousands of times more concentrated
than any light from any other kind of light source. This concentration
of light can cause instant eye injuries, primarily by burning the retina
(the back of your eyeball contatining cells that are sensitive to light).
Even if you cannot feel “heat” from a laser beam, it can still poten-
tially injure or blind you or your audience. Even very small amounts
of laser beam light are potentially hazardous even at long distances.
Laser eye injuries can be sustained faster than you can blink.
Do not think that because this laser splits the laser beam into hun-
dreds of beams and that the laser beam is scanned out in high
speed, that an individual laser beam is safe for eye exposure. This
laser uses dozens of milliwatts of laser power (Class 3B levels inter-
nally) before it splits into multiple beams (Class 3R levels). Many of
the individual beams are potentially hazardous to the eyes.
Do not that because the laser light is moving, it is safe. This is not
true. Nor, do the laser beams always move. Since eye injuries can
occur instantly, it is critical to prevent even the smallest possibility of
any direct eye exposure. In the laser safety regulation, it is not legal
to aim Class 3R lasers in areas which people can get exposed. This
is true even if it is aimed below people’s faces, such as on a dance
oor.
Do not operate the laser without rst reading and understanding
all safety and technical data in this manual.
Always set up and install all laser effects so that all laser light is at
least 3 meters (9.8 feet) above the oor on which people can stand.
© ®American DJ Supply - www.americandj.com - Fusion Scan 250™ User Manual Page 6
Fusion Scan 250™ Laser Warnings and Safety
After setting up, and before public use, test laser to ensure proper
function. Do not use if any defect is detected. Do not use if laser
emits only one or two laser beams rather than dozens/hundreds, as
this could indicate damage to the diffraction grating optic, and could
allow emission of higher laser levels above Class 3R.
Do not point lasers at people or animals. Never look into the laser
aperture or laser beams.
Do not point lasers in areas in which people can potentially get
exposed, such as uncontrolled balconies, etc.
Do not point lasers at highly reective surfaces, such as windows,
mirrors and shiny metal. Even laser reections can be hazardous.
Never point a laser at aircraft, this is a federal offense.
Never point un-terminated laser beams into the sky.
Do not expose the output optic (aperture) to cleaning chemicals.
Do not use laser if the laser appears to be emitting only one or two
beams.
Do not use the laser if the housing is damaged, the housing is open,
or if the optics appear damaged in any way.
Never open the laser housing. The high laser power levels inside of
the protective housing can start res, burn skin and will cause instant
eye injury.
Never leave this device running unattended.
The operation of a class 3R laser show is only allowed if the show
is controlled by a skilled and well- trained operator, familiar with the
data included in this manual.
The legal requirements for using laser entertainment products vary
from country to country. The user is responsible for the legal require-
ments at the location/country of use.
Always use proper lighting safety cables when hanging lights and
effects overhead.
Product specificaties
| Merk: | American Audio |
| Categorie: | Niet gecategoriseerd |
| Model: | Fusion Scan 250 |
Heb je hulp nodig?
Als je hulp nodig hebt met American Audio Fusion Scan 250 stel dan hieronder een vraag en andere gebruikers zullen je antwoorden
Handleiding Niet gecategoriseerd American Audio
14 Augustus 2025
14 Augustus 2025
14 Augustus 2025
14 Augustus 2025
14 Augustus 2025
14 Augustus 2025
14 Augustus 2025
14 Augustus 2025
14 Augustus 2025
14 Augustus 2025
Handleiding Niet gecategoriseerd
- IODD
- SMC
- Sedona
- Energy Sistem
- Kata
- Gasmate
- Enerdrive
- USL
- Peavey
- Ensemble Designs
- Extralife Instruments
- ACOPower
- Bontempi
- Hirschmann
- Cottons
Nieuwste handleidingen voor Niet gecategoriseerd
14 Augustus 2025
14 Augustus 2025
14 Augustus 2025
14 Augustus 2025
14 Augustus 2025
14 Augustus 2025
14 Augustus 2025
14 Augustus 2025
14 Augustus 2025
14 Augustus 2025
