User Instructions
© ®American DJ - www.americandj.com - Tri Beam™ Instruction Manual Page 2
Introduction: Thank you for purchasing the American DJ Tri Beam.®
™
The Tri Beam™ is a unique three color, three channel, DMX intelligent ,
laser effect that creates different patterns. The unit uses eight inter-
nal mirrors to bounce the laser reection over a wide area. This unit
can be used as a stand alone, sound-active unit or in a Master/Slave
conguration. The unit can also be controlled via DMX controller. The
unit’s sound sensitivity may be adjusted by a sensitivity adjustment on
the back of the unit. The unit may be mounted in either a horizontal or
vertical position.
Unpacking: Every Tri Beam™ has been thoroughly tested and has
been shipped in perfect operating condition. Carefully check the ship-
ping carton for damage that may have occurred during shipping. If
the carton appears to be damaged, carefully inspect the unit for any
damage and be sure all accessories necessary to operate the unit
have arrived intact. In the event damage has been found or parts are
missing, please contact our toll free customer support number for fur-
ther instructions. Please do not return the unit to your dealer without
rst contacting customer support.
Customer Support: American DJ® provides a toll free customer
support line, to provide set up help and to answer any question should
you encounter problems during your set up or initial operation. You
may also visit us on the web at www.americandj.com for any com-
ments or suggestions. For service related issue please contact Ameri-
can DJ .® Service Hours are Monday through Friday 9:00 a.m. to 5:00
p.m. Pacic Standard Time.
Voice: (800) 322-6337
Fax: (323) 582-2610
E-mail: support@americandj.com
To purchase parts online visit http://parts.americandj.com
Warning! To prevent or reduce the risk of electrical shock or re, do
not expose this unit to rain or moisture.
Caution! There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures
warranty. In the unlikely event your unit may require service please
contact American DJ customer support.
PLEASE recycle the shipping carton whenever possible.
Tri Beam™ General Introduction
Rev. 10/09
American DJ®
© ®American DJ - www.americandj.com - Tri Beam™ Instruction Manual Page 4© ®American DJ - www.americandj.com - Tri Beam™ Instruction Manual Page 3
Please carefully read and understand the instructions in this manual
thoroughly before attempting to operate this unit. These instructions
contain important safety information regarding the use and mainte-
nance of this unit. Please keep this manual with the unit, for future
reference.
CAUTION IMPORTANT! When installing this projector, make sure
that it is mounted in a manner that prevents the audience from
looking directly into the beam, and the beam from striking the
audience.
Tri Beam™ General Instructions Tri Beam™ Safety Precautions
• To reduce the risk of electrical shock or re, do not expose this unit
rain or moisture.
• Do not spill water or other liquids into or on to your unit.
• Do not attempt to remove or break off the ground prong from the
electrical cord. This prong is used to reduce the risk of electrical
shock and re in case of an internal short. Do not attempt to oper-
ate this unit if the power cord has been frayed or broken.
• Disconnect from main power before making any type of connection.
• Do not remove the cover under any conditions. There are no user
serviceable parts inside.
• Always be sure to mount this unit in an area that will allow proper
ventilation. Allow about 6” (15cm) between this device and a wall.
• Do not attempt to operate this unit, if it becomes damaged.
• This unit is intended for indoor use only, use of this product out-
doors voids all warranties.
• During long periods of non-use, disconnect the unit’s main power.
• Always mount this unit in safe and stable matter.
• Power cords should be routed so they are not likely to be walked
on, pinched by items placed upon or against them.
• Cleaning -The fixture should be cleaned only as recommended by
the manufacturer. See page 9 for cleaning details.
• Heat -The appliance should be situated away from heat sources
such as radiators, heat registers, stoves, or other appliances
(including amplifiers) that produce heat.
• The fixture should be serviced by qualified service personnel when:
A. The power-supply cord or the plug has been damaged.
B. Objects have fallen, or liquid has been spilled into the unit.
C. The unit has been exposed to rain or water.
D. The unit does not appear to operate normally or exhibits a
marked change in performance.
Tri Beam™ Features
Tri Beam™ Warranty Registration
The Tri Beam™ carries a imited warranty. Please fill out the 90 day l
enclosed warranty card to validate your purchase. All returned service
items whether under warranty or not, must be freight pre-paid and
accompany a return authorization (R.A.) number. If the unit is under
warranty you must provide a proof of purchase invoice. copy of your
Please contact American DJ customer support for a R.A. number.®
DANGER
VISIBLE LASER RADIATION
-AVOID DIRECT EYE EXPOSURE
LASER DIODE
WAVELENGTH : 635~650 nm
Max Output : <4.9mW
Class IIIa Laser Product
!
!
• 4.9mW Red and Green Laser Diodes
• 3 Laser Colors (Red and Green combine to make Yellow)
• Built-In Hanging Yoke
• Internal Microphone Sound Active with
• Audio Sensitivity Knob
• 2 Operating Modes: DMX Control & Stand Alone
© ®American DJ - www.americandj.com - Tri Beam™ Instruction Manual Page 5
© ®American DJ - www.americandj.com - Tri Beam™ Instruction Manual Page 6
Tri Beam™ Laser Warnings and Safety Tri Beam™ Laser Warnings and Safety
NON-INTERLOCKED HOUSING WARNING
The Tri Beam
™
contains high power laser devices internally. Do not
open the laser housing, due to the potential exposure to unsafe levels
of laser radiation. The laser power levels, if the unit is opened, can
cause instant blindness, skin burns and res.
STOP AND READ ALL LASER SAFETY DATA
OPERATION INSTRUCTIONS AND LASER SAFETY
The light source emitted from this product can potentially cause eye
injury if not set up and used properly. The light source emitted from a
laser is very different from any other light sources with which you may
be aware of. Laser light is thousands of times more concentrated
than any light from any other kind of light source. This concentration
of light can cause instant eye injuries, primarily by burning the retina
(the back of your eyeball contatining cells that are sensitive to light).
Even if you cannot feel “heat” from a laser beam, it can still poten-
tially injure or blind you or your audience. Even very small amounts
of laser beam light are potentially hazardous even at long distances.
Laser eye injuries can be sustained faster than you can blink.
Do not think that because this laser splits the laser beam into hun-
dreds of beams and that the laser beam is scanned out in high
speed, that an individual laser beam is safe for eye exposure. This
laser uses dozens of milliwatts of laser power (Class 3B levels inter-
nally) before it splits into multiple beams (Class 3R levels). Many of
the individual beams are potentially hazardous to the eyes.
Do not that because the laser light is moving, it is safe. This is not
true. Nor, do the laser beams always move. Since eye injuries can
occur instantly, it is critical to prevent even the smallest possibility of
any direct eye exposure. In the laser safety regulation, it is not legal
to aim Class 3R lasers in areas which people can get exposed. This
is true even if it is aimed below people’s faces, such as on a dance
oor.
Do not operate the laser without rst reading and understanding
all safety and technical data in this manual.
Always set up and install all laser effects so that all laser light is at
least 3 meters (9.8 feet) above the oor on which people can stand.
After setting up, and before public use, test laser to ensure proper
function. Do not use if any defect is detected. Do not use if laser
emits only one or two laser beams rather than dozens/hundreds, as
this could indicate damage to the diffraction grating optic, and could
allow emission of higher laser levels above Class 3R.
Do not point lasers at people or animals. Never look into the laser
aperture or laser beams.
Do not point lasers in areas in which people can potentially get
exposed, such as uncontrolled balconies, etc.
Do not point lasers at highly reective surfaces, such as windows,
mirrors and shiny metal. Even laser reections can be hazardous.
Never point a laser at aircraft, this is a federal offense.
Never point un-terminated laser beams into the sky.
Do not expose the output optic (aperture) to cleaning chemicals.
Do not use laser if the laser appears to be emitting only one or two
beams.
Do not use the laser if the housing is damaged, the housing is open,
or if the optics appear damaged in any way.
Never open the laser housing. The high laser power levels inside of
the protective housing can start res, burn skin and will cause instant
eye injury.
Never leave this device running unattended.
The operation of a class 3R laser show is only allowed if the show
is controlled by a skilled and well- trained operator, familiar with the
data included in this manual.
The legal requirements for using laser entertainment products vary
from country to country. The user is responsible for the legal require-
ments at the location/country of use.
Always use proper lighting safety cables when hanging lights and
effects overhead.
