Bekijk gratis de handleiding van Airlive IGM-14104BT-1.25G (96 pagina’s), behorend tot de categorie Schakelaar. Deze gids werd als nuttig beoordeeld door 6 mensen en kreeg gemiddeld 4.4 sterren uit 3.5 reviews. Heb je een vraag over Airlive IGM-14104BT-1.25G of wil je andere gebruikers van dit product iets vragen? Stel een vraag
Pagina 1/96
IGM-642POE/BT series
IGM-1082POE/BT series
IGM-1484POE series
IGM-14104BT series
6/10/14 Port Managed Industrial
Gigabit PoE Switch
Web Manual
Ver. 1.1
Ver. 1.1
II
0 Foreword ..................................................................................... 6
0.1 Target Audience ..................................................................... 6
0.2 Manual Convention ................................................................. 6
1 Management Software Specification ................................................... 7
2 Web Page Login ............................................................................ 9
2.1 Log in the Network Management Client ........................................ 9
3 Network Admin ............................................................................ 10
3.1 IP Config ............................................................................ 10
3.2 IP Status ............................................................................ 11
3.3 NTP .................................................................................. 12
3.4 Syslog ............................................................................... 13
3.5 SNMP ................................................................................ 14
4 Port Configure ............................................................................ 19
4.1 Ports ................................................................................. 19
4.2 Aggregation ........................................................................ 20
4.2.1 Static ......................................................................... 21
4.2.2 LACP ......................................................................... 22
4.3 Mirroring ............................................................................ 25
4.4 Green Ethernet .................................................................... 27
4.5 DDM ................................................................................. 27
5 PoE .......................................................................................... 29
5.1 PoE Setting ........................................................................ 29
5.2 PoE Status ......................................................................... 30
6 Advanced Configure ..................................................................... 31
6.1 MAC Table .......................................................................... 31
6.2 VLANS .............................................................................. 32
6.3 GVRP ................................................................................ 37
6.4 Port Isolation ...................................................................... 39
6.5 Loop Protection ................................................................... 41
6.6 Spanning Tree ..................................................................... 42
6.6.1 Bridge Configuration ..................................................... 43
6.6.2 MSTI Mapping .............................................................. 44
6.6.3 MSTI Priorities ............................................................. 45
6.6.4 CIST Ports .................................................................. 45
6.6.5 MSTI Ports .................................................................. 47
6.7 IPMC Profile ........................................................................ 48
6.8 IGMP Snooping .................................................................... 48
6.8.1 Basic Configuration ...................................................... 49
6.8.2 VLAN Configuration ...................................................... 50
6.8.3 Port Filtering Profile ...................................................... 51
6.9 IPv6 MLD Snooping .............................................................. 52
6.9.1 Basic Configuration ...................................................... 52
6.9.2 VLAN Configuration ...................................................... 53
