Service Manual Digital InterLock Coffee Grinders
For the Latest speciFications and inFormation go to www.wiLburcurtis.com
This appliance is designed for commercial use. Any servicing other than cleaning and maintenance should be performed by an autho-
rized Wilbur Curtis service center.
•DoNOTimmersetheunitinwateroranyotherliquid
•Toreducetheriskofreorelectricshock,doNOTopentoppanel.Nouserserviceablepartsinside.Repairshouldbedone
only by authorized service personnel.
•Keephandsandotheritemsawayfromhotpartsofunitduringoperation.
•Nevercleanwithscouringpowdersorharshimplements.
Important Safeguards/Conventions
Conventions
WARNINGS–TohelpavoidpersonalinjuryImportantNotes/Cautions–fromthefactory
QUICKSTART&SETUP
SETUP
1.Installthegrinderonarm,levelbaseinalocationwhereitcanbeconnectedtoagroundedelectricaloutletof120VAC,ratedat15
amps.
2.Testtheunitbyrunningsomewholebeancoffeethroughthegrinder.Ifanyproblemsareencountered,refertothetroubleshooting
sectioncompleteatwww.wilburcurtis.comorcallTechnicalSupportat800-995-0417.
CONNECTINGTHEINTERLOCKGRINDER
1.TurnbothunitsOFF.
2.PlacethegrindercloseenoughtothebrewersoittheInterLockcablewillreachthebrewer.
3.Locatethejack,labeledCLASS2WIRINGONLY,onthebackofthebrewer.PlugintheInterLockcabelfromthegrinder.
4.TurnbothunitsON.Interlockingiscomplete.
INTERLOCKOPERATINGINSTRUCTIONS
1.Openthedoorontopofthegrinderandllwithfreshwholebeancoffee.Closethetopdoor.
2.PlaceanemptySatelliteonthewarmerdeckofthebrewerandpreheatitbyswitchingonwarmer.
3.Placeanewpaperlterintothebrewcone.
4.Insertthebrewconeintothebasketholderarmsonthegrinder.
5.Presstheappropriategrindswitch(SMALL,MEDIUMorLARGE).
6.Allowthegrindmotortocompletelystopbeforeremovingthebrewcone.Thebrew
selectionisnow“Locked”inatthebrewerandisindicatedbytheashinglightonthe
InterLockbrewer.
7.Transferthelledbrewconetothebrewerandpresstheashingbrewbutton.
Brewcycleiscompletewhenthebrewlightstopsashing.
ADJUSTINGTHEGRINDS
1.Emptyhopperofcoffeebeans.Rungrindertocleargrindingburrsofcoffee.
2.Openhousingcovertolocateadjustmentscrew(8)andlocknut(7).Loosenlocknut.
3.Runmotorduringadjustment.Turningadjustmentscrewclockwisewillresultinaner
grind(if,whileturning,youhearthegrindingburrsstartingtotouch,immediately,back
off1/8thturn).Turningcounterclockwisewillproduceacoarsergrind.
4.Withascrewdriverholdingtheadjustmentscrewinplace,tightenthelocknut.
5.Runsomecoffeebeansthroughthemachinetocheckthegrindadjustment.
6.Replacefrontcoveronmachine.
*Thisadjustmentmaychangetheamountofgroundcoffeedispensed.
CHANGINGABROKENSHEARDISK
1.Unplugthepowercord.
2.Emptythehopperofbeans.
3.Takeoutthethumbscrews(10)toremovethegrindcap(6).
4.Pulloutthegrindingburr/feedwormassembly(2).Theinnerhalfofthegrindingburrset
willremaininthehousing.
5.Separatetheshearcap(5)andsheardrive(3).Thesnappedsheardisk(4)shouldfall
out of its slot on the shear drive.
6.Inspectandcleanhousing(1)ofanycoffeeordebris.Especiallylookforanythingthatmayhavebrokenthesheardisk.
7.Re-insertthefeedwormandgrindingburrontothemotorshaft.
8.Pushsheardrivethroughburr/feedwormassemblyandalignlargeslotwithtongueonthemotorshaft.
9.Rotateburr/feedwormassemblytoalignslotwithnarrowslotonsheardrive.
10.Insertanewsheardiskintoslot.Coverwiththeshearcap.
11.Replacegrindcapandthumbscrews.
