Pagina 1/7
The Qi Etherealizer (pronounced “chee ethereal-izer”), a collaborative creation with Yvette Young,
is a multi-effects pedal that combines Chorus, Delay, Granular effects, and, of course, Reverb, into a
creative playground for atmospheric exploration. Mix and match the chorus, delay, and grain and run
in series or parallel to create your own inspiring universe of possibility in a stereo field. With the ability
to save presets and bypass the chorus, delay, and grain controls, you can quickly and instantly change
settings by simultaneously pressing the Bypass and Freeze stomp switches. Go from a traditional
chorus with a little bit of delay, or go all in and let the Qi take over with unexplainable washes of
glitchy and lush ambiance. Whatever your style is, the Qi will give it a new life.
*The use of an isolated power supply is recommended for powering all Walrus Audio Pedals.
Daisy chain power supplies are not recommended.
Got questions or need a repair?
Email help@walrusaudio.com to talk with a real live human about your Walrus gear!
This product comes with a limited lifetime warranty.
Click Here for more info.
9 volt DC, Center Negative • 300mA min*
First, it’s important to know that the Qi can run in series or parallel.
Depending on which routing method you’re using, each effect’s Mix
knob will work differently. Change the routing order by simply pressing
the Flow button. The LED will tell you which one you’ve selected.
SERIES - In series, each effect feeds into the next, just as if they were
separate pedals on a pedal board next to each other with a master
reverb, filter, and wet/dry mix at the end.
In Series, the order of effects is:
Chorus > Delay > Grain > Reverb > Tone > Dry > Output
In Series mode, the controls the mix between the Dry Mix / Dry knob
& Wet signal. At minimum, you will only hear the dry guitar signal. At
maximum, you will only hear the wet (affected) signal.
In Series mode, each effect’s Mix knob performs a wet/dry mix between
the processed signal and input signal to that effect.
PARALLEL - In parallel, each effect processes
separately. The individual effect outputs are
not feed into each other.
In Parallel mode, the controMix / Dry knob
input signal. At minimum, you will only hear
the effects that are currently activated. At m
dry signal will be at unity.
In Parallel mode, each effect’s Mix knob funct
setting the effect’s output volume level.
TONE: Controls the cutoff of a resonant low pass filter. Turning
the knob counter-clockwise will remove higher frequencies
from the wet effects.
SPACE: Smooths out the wet effects by applying a lush hall-
style reverb. Go from small room sounds at minimum to large
ambient sounds with long decays at maximum.
Note: The reverb will only apply to wet effects, not the
dry signal.
The Qi is equipped with a Chorus, Delay, and Grain Sampler.
Each effect was lovingly and meticulously created to Yvette’s
preferences. The effects can be used independently, all together, or
any combination with each other. Each effect can be turned on/off
by pressing and holding the toggle button, turning the effect’s Mix
knob to minimum, or via MIDI.
CHORUS: Choose from two different flavors of modulation:
Tri Chorus: A wide, rich-sounding chorus with three delay
lines with phase offset modulation applied to each delay line
resulting in a lush modulated signal.
Stereo: Classic chorus effect with the added benefit of stereo
width by offsetting the modulation by 180 degrees in the right
channel. Note that in Stereo mode, turning the Chorus Mix
knob fully clockwise will create a Vibrato sound.
Rate: Controls the rate of the modulating LFO. A higher rate will
produce a faster and more pronounced pitch modulation, while
a lower rate will produce a slower and more subtle effect.
Depth: Co
the amou
