What’s in the box

Connect the Camera

x 2

x 2

Quick start guide

Your baby monitor package contains the following items. Save your sales receipt and original

packaging in the event warranty service is necessary.

Overview

• Use only the power adapter supplied with this product.

• Make sure the camera is not connected to an electronically controlled electric power outlet.

• Connect the power adapter in a vertical or floor mount position only. The adapter’ prongs are not

designed to hold the weight of the camera, so do not connect it to any ceiling, under-the-table, or cabinet

outlets. Otherwise, the adapter may not properly connect to the outlet.

• Make sure the camera and the power adapter cord are out of reach of children.

Important safety instructions

The applied nameplate is located at the bottom of the camera’s

base. When using your equipment, basic safety precautions

should always be followed to reduce the risk of fire, electric shock

and injury, including the following:

1. Follow all warnings and instructions marked on the product.

2. Adult setup is required.

3. CAUTION: Do not install the camera at a height above 2

meters.

4. This product is intended as an aid. It is not a substitute for

responsible and proper adult supervision and should not be

used as such.

5. This product is not intended for use as a medical monitor.

6. Do not use this product near water, for example, near to a

bath, sink, swimming pool or shower.

7. Use only the adapter included with this product. Incorrect

adapter polarity or voltage can seriously damage the product.

Power adapter information:

Camera Output: 5V 1A;

VTech Telecommunications Ltd.;

Model: VT05EUS05100

-OR-

Jiangxi Jian Aohai Technology Co., Ltd.

Model: A318-050100W-US2

8. The power adapter is intended to be correctly oriented in a

vertical or floor mount position. The prongs are not designed

to hold the plug in place if it is plugged into a ceiling, under-

the-table or cabinet outlet.

9. For pluggable equipment, the socket-outlet (power adapter)

should be installed near the equipment and should be easily

accessible.

10. Unplug this product from the wall outlet before cleaning.

Do not use liquid or aerosol cleaners. Use a damp cloth for

cleaning.

11. Do not modify the power adapter or replace with other power

adapter, as this causes a hazardous situation.

12. Do not allow anything to rest on the power cord. Do not install

this product where the cord may be walked on or crimped.

13. This product should be operated only from the type of power

source indicated on the marking label. If you are not sure of

the type of power supply in your home, consult your retailer

or electricity supply provider.

14. Do not overload wall outlets or use an extension cord.

15. Do not place this product on an unstable table, shelf, stand or

other unstable surfaces.

16. This product should not be placed in any area where proper

ventilation is not provided. Slots and openings in the back or

bottom of this product are provided for ventilation. To protect

them from overheating, these openings must not be blocked

by placing the product on a soft surface such as a bed, sofa

or rug. This product should never be placed near or over a

radiator or heat source.

17. Never push objects of any kind into this product through

the slots because they may touch dangerous voltage points

or create a short circuit. Never spill liquid of any kind on the

product.

18. To reduce the risk of electric shock, do not disassemble this

product, but take it to an authorized service facility. Opening

or removing parts of the product other than specified access

doors may expose you to dangerous voltages or other risks.

Incorrect reassembling can cause electric shock when the

product is subsequently used.

19. You should test the sound reception every time you turn on

the units or move one of the components.

20. Periodically examine all components for damage.

21. There is a very low risk of privacy loss when using certain

electronic devices, such as baby monitors, cordless

telephones, etc. To protect your privacy, make sure the

product has never been used before purchase, reset the baby

monitor periodically by powering off and then powering

on the units, and power off the baby monitor if you are not

intending to use it for some time.

22. Children should be supervised to ensure that they do not play

with the product.

23. The small parts of this monitor can be swallowed by babies or

small children. Keep these parts out of reach of children.

24. The product is not intended for use by persons (including

children) with reduced physical, sensory or mental capabilities,

or lack of experience and knowledge, unless they have

been given supervision or instruction concerning use of the

appliance by a person responsible for their safety.

SAVE THESE INSTRUCTIONS

Cautions

1. Use and store the product at a temperature between 32

o

F

(0

o

C) and 104

o

F (40

o

C).

2. Do not expose the product to extreme cold, heat or direct

sunlight. Do not put the product close to a heating source.

3. Warning—Strangulation Hazard—Children

have STRANGLED in cords. Keep this cord out of

the reach of children (more than 3 ft (0.9m) away).

Do not remove warning label on the adapter cord.

4. Never place the camera(s) inside the baby’s crib or playpen.

Never cover the camera(s) with anything such as a towel or a

blanket.

5. Other electronic products may cause interference with your

camera. Try installing your camera as far away from these

electronic devices as possible: wireless routers, radios, mobile

phones, intercoms, room monitors, televisions, personal

computers, kitchen appliances and cordless telephones.

Precautions for users of implanted cardiac pacemakers

Cardiac pacemakers (applies only to digital cordless devices):

Wireless Technology Research, LLC (WTR), an independent

research entity, led a multidisciplinary evaluation of the

interference between portable wireless devices and implanted

cardiac pacemakers. Supported by the U.S. Food and Drug

Administration, WTR recommends to physicians that:

Pacemaker patients

• Should keep wireless devices at least six inches from the

pacemaker.

• Should NOT place wireless devices directly over the

pacemaker, such as in a breast pocket, when it is turned ON.

WTR’s evaluation did not identify any risk to bystanders with

pacemakers from other persons using wireless devices.

Electromagnetic elds (EMF)

This VTech product complies with all standards regarding

electromagnetic fields (EMF). If handled properly and according

to the instructions in this user’s manual, the product is safe to be

used based on scientific evidence available today.

Position the Camera

Use the app to pan and Tilt your camera.

RM9761

Quick start guide

Pan and Tilt Camera

RM9761

For more support information:

S

m

Go to www.vtechphones.com

to register your product for

enhanced warranty support and

latest VTech product news.

Technical specications

Frequency controlCrystal controlled PLL synthesizer

Transmit frequency2412 - 2462 MHz

Channels11

Nominal effective rangeMaximum power allowed by FCC and IC. Actual operating range

may vary according to environmental conditions at the time of use.

Power requirementsPower adapter output: 5V DC @ 1A

Specifications are subject to change without notice.

© 2023 VTech Communications, Inc. All rights reserved. 11/23.

RM9761_QSG_US_V1.

UL STD.

62368-1

CERTIFIED TO

CSA STD.

C22.2 NO.62368-1

CONFORMS TO

Product Recycling

Recycle this product when you are done with it.

For more information, scan the QR code

or visit vtechphones.com/recycle.

Strangulation

Hazard

Keep this cord out of reach of children.

The cord needs to be at least three feet

away from the child at all times. Do not

use with an extension cord. Do not

remove this tag.

Éloignez ce cordon des enfants. Le

cordon doit se trouver à au moins trois

pieds d’un enfant et ce, en tout temps.

N’utilisez pas de rallonge. Ne retirez pas

cette étiquette.

Mantenga este cable fuera de la alcance

de los niños. Este cable debe estar por

lo menos tres pies fuera de la alcance

del niño en todo momento. No lo use

con una extensión inalámbrica. No quite

esta etiqueta.

Risque

d’étranglement

Riesgo de

estrangulación

Strangulatio

n

Hazard

Keep this cord

out of reach of child

ren.

The co

r

d ne

eds to

be at least three

f

ee

t

away fr

o

m the child at all times. Do

not

use with an extension cord. Do not

re

move this ta

g.

Éloignez ce cor

don des enfants. Le

cordon doit se trouver à au moins trois

pieds d’un

enfant et ce, en tout temps.

N’

ut

ilisez

pas

d

e ra

llon

ge.

N

e

ret

ir

ez

pas

cette étiquette.

M

an

tenga este cable f

u

era de la alcance

de los niños. Este cable debe estar por

lo menos tres pies fuera de la alcance

del niño en todo momento. No lo

u

se

con

u

na extensión inalámbrica.

N

o

quite

es

t

a etiqueta.

Risque

d’

étr

anglement

Riesgo de

est

ra

ngula

c

ión

1Light sensor

2Camera lens

3Microphone

4Infrared LEDs

• Allow you to see clearly in a dark

environment.

5Night light

6

Night Light Control Key

7Privacy Mode on/off switch

8Power LED indicator / Privacy LED

indicator

• The LED initially turns on when power

is first applied, then turns off after a

short time. Once turned off, the LED

indicates the privacy mode status.

9Speaker

10Power jack

11Temperature sensor

12Slots for wall mounting

13PAIR/RESET key

• Press and hold to pair the camera with

your mobile devices.

5

6

7

3

4

2

1

8

9

10

11

12

13

>

3ft (1m)

Privacy Mode

Designed for extra peace of mind, turn on

Privacy Mode for a moment of peace and quiet.

When the Privacy Mode is turned on, audio

transmission and video monitoring will be

disabled. So motion recording, motion detection,

and sound detection will be temporarily

unavailable.

You can play melodies/lullaby, and turn on night

light on the app.

After installing the MyVTech Baby Plus App...

• Sign up for an account

• Pair the camera with your mobile device

• Monitor your baby using a wide range of features

Start monitoring from anywhere.

Download the free MyVTech Baby Plus mobile app and install it to a mobile device, then use your

mobile device and the mobile app to monitor your areas remotely.

Download app for mobile access

Pair the Camera with your Mobile Device

App Compatibility

• Android

TM

6.0 or later

• iOS 12 or later.

On Baby Plus App

Before you start...

• Connect your mobile device to a 2.4GHz home Wi-Fi network for a better connection and smoother

video streaming.

• Enable the Location Service of your mobile device for the purpose of camera setup.

With a 2.4GHz home Wi-Fi network and enabled Location Service...

You can start to pair the camera with your own mobile device following the instructions in the app.

Upon the successful pairing, you can hear and watch your baby via your mobile device.

Tips:

• Move the camera and the Wi-Fi router closer to each other in order to strengthen the network signal.

• It takes up around 1 minute to search the camera.

P

L

U

S

P

L

U

S

Connect the power adapter to the camera and a power supply, then the camera powers on

automatically.

• Slide the Privacy on/off switch to to enter

the privacy mode.

• Slide the Privacy on/off switch to to

resume video monitoring.

Tips:

• The Privacy LED indicator lights steady in red when

privacy mode is on, and changes to green when

privacy mode is off.

• Turn on/off the Privacy LED indicator on the app.

You can control the night light remotely from the MyVTech Baby Plus app, or directly on the

camera.

Adjust the night light on the Camera

• Tap the Night light control key located on the

top of the camera to turn on/off the night light.

• Tap and hold (with the light turned on) the Night

light control key to adjust the night light

brightness.

Note:

• If Auto Brightness has been pre-selected,

any adjustment in night light brightness will

automatically turn off Auto Brightness mode and

switch to the fixed level of brightness.

Night Light

Product specificaties
