www.vitekcctv.com

RELATED PRODUCTS AND ACCESSORIES!

AN ALL-IN-ONE SECURITY SOLUTION!

The VITEK Transcendent Series NDAA Compliant 6 Megapixel

Panoramic Fisheye Network Camera enables complete visual

coverage of a 360 degree area. Complete image may be split

or de-warped into 3 separate images which can be manipulated

for closer inspection by digital Pan Tilt and zoom within each

divided image.

Features include Infrared LEDs for viewing in total darkness,

2-Way Audio and a micro SD card slot for local recording. One

or more can be used as an overview in a sophisticated network

video solution or as an All-in-One Video Surveillance system

with Mobile applications supporting Virtual Reality mode.

Transcendent Series NDAA Compliant 6 MegaPixel

Indoor/Outdoor IP67 Compact IP Vandal 360° Fisheye Camera

VTD-TND6FPN

• 1/2.5” 6.0 MegaPixel CMOS Image Sensor

• Up to 30fps live view @ 6 MegaPixel (2160×2160)

- Panoramic View: 15fps @ (3200×1800 / 1920×1080)

• True (120dB) Wide Dynamic Range

•1.65mm @F2.0, horizontal field of view: 180° (Wall mounting),

360° (Ceiling mounting)

• 4 High Power Covert IR LEDs with up to 65’ IR Range

• True Mechanical Day / Night function by ICR

• XD-DNR (2D-DNR & 3D-DNR) Noise Reduction

• ROI Encoding

• H.265+ / H.265 / H.264+ / H.264 / MJPEG

• Secondary Video Output (CVBS)

• Programmable Analytics: Region Intrusion, Target Counting

(Human / Vehicle classification), Crowd Density, Heat Map

• Remote Viewing via VMS, Web Browse, iOS & Android Apps

• ONVIF Compliant

• MicroSD memory card slot for Local recording supporting up to 256GB

• Optional Junction Box (VT-TJB-F1), Pedestal (VT-TPDM-F), and

Wall (VT-TWM-F) Mounts Available

• IP67 Ingress Protection

• Two Way Audio* (Amplified speaker required)

• 12VDC & PoE (Power over Ethernet) Operation

KEY FEATURES

*Research local, state and federal laws regarding the implementation of audio surveillance.

MULTIPLE VIEWS

VT-TJB-F1

Junction Box for

Cable Management

with VTD-TND6FPN

Pair with VITEK Transcendent Series

Network Recorders VT-TNR818PF,

VT-TNR1646PF, and VT-TNR3216PF with

Built-in PoE and Fully Programmable

Intelligent Analytics including Facial

Detection.

VT-TWM-F

Wall Mount for

VTD-TND6FPN

VT-TPM-F

Pedestal / Pendant

Mount for

VTD-TND6FPN

VT-TPLMT

Universal

Transcendent Pole

Mount Adapter -

reqs. VT-TWM-F

VT-TCNMT

Universal

Transcendent

Corner Mount Adapter -

reqs. VT-TWM-F

1/2024 : REV-1.1
