www.vitekcctv.com

VTC-TNT4MEA

10/2024 : REV-1.0

Transcendent Series 4 MegaPixel Motorized AF IP WDR

Turret Camera with Programmable Analytics

• 1/3.0” 4.0 MegaPixel CMOS Image Sensor

• Up to 30fps @ 4MP (2688 × 1520)

•2.8~12mm Motorized Varifocal Lens

•Matrix IR (up to 165’ IR Range), White Light (up to 130’)

•True Wide Dynamic Range (120dB)

•True Mechanical Day/Night function by ICR

•XD-DNR (3D & 2D-DNR) Noise Reduction

• Programmable Analytics: Region Intrusion Detection, Object Abandoned /

Missing, Scene Change Detection, Line Crossing, Video Blur, Video Color

Cast Detection

•H.265+ / H.265 / H.264+ / H.264 / MJPEG

•MicroSD Card Slot for Local Recording (Up to 256GB)

•1 Ch. Audio In + Built-in Mic*

• Remote Viewing via VMS, Internet Explorer (Plug-in Req’d),

Edge in IE Mode, and iOS & Android Apps

•ONVIF Compliant

•IP67 Weather Resistance

•Optional J-Boxes, Wall and Pendant Mounting Options, plus pole and

corner adapters - see below

•12VDC & PoE (Power over Ethernet) Operation

•3-Year Warranty

KEY FEATURES

*Please research local, state and federal laws regarding the implementation of audio surveillance.

TRANSCENDENT SERIES NDAA

COMPLIANT IP CAMERAS WITH

PROGRAMMABLE ANALYTICS!

Transcendent Series NDAA Compliant High Definition 4 Megapixel IP

Network Cameras offer unprecedented performance and value. These

simple, easy to install, attractively styled, IP Network Cameras transmit

over remote viewing via VMS, Web Browser, and iOS & Android Apps.

These models also feature enhanced night vision using White Light

emitters.

*Also available in Charcoal,

VTC-TNT4MEAB

TRANSCENDENT ANALYTICS!

AREA

Fully Programmable

Regional Intrusion

Detection

OBJECT TRACKING

Track Objects Removed

from or Abandoned in

Secure Areas

LINE CROSSING

Track People or

Vehicles Entering /

Exiting Designated

Areas

Pair with one of several VITEK

Transcendent Series Network or

Digital Recorders offering a Myriad

of Advanced Analytic Functions

and Applications. See

www.vitekcctv.com for More!

Firmware and Features may be upgraded

periodically – Please contact your VITEK

Representative for complete information on

updates and downloads.

RELATED PRODUCTS & ACCESSORIES

CABLE CONNECTIONS

Ethernet (PoE), 12VDC

Input, Audio In*

TRANSCENDENTNETWORKINTEGRATED

AUDIO

4 MEGAPIXELMATRIX IR LED

ILLUMINATION

MOTORIZED

VARIFOCAL LENS

MICRO SD CARD SLOT

Supporting up to 256GB

MicroSD Cards

PROGRAMMABLE

ANALYTICS

5.15”(130.7mm)

4.30”

(109.3mm)

VT-TPLMT

Universal Pole Adapter:

Mount directly with J-Box

VT-TJB021 or VT-TJB01

Wall mounting option is

VT-TM01 (reqs VT-TJB021)

VT-TCNMT

Universal Corner Adapter:

Mount directly with J-Box

VT-TJB021 or VT-TJB01

Wall mounting option is

VT-TM01 (reqs VT-TJB021)

VT-TPDM-2

Optional Pendant Mount

(VT-TJB01 Req)

VT-TPDM-3

Optional Pendant Mount

(VT-TJB021 Req)

VT-TJB01

Optional Junction box for

Cable Management

VT-TJB021

Optional Junction box for

Cable Management

VT-TWMT-4

Optional Wall Mount

VT-TWM01

Optional Wall Mount

(VT-TJB021 Req)

BREAKDOWN OF MODEL NUMBERS EXAMPLE: VTC-TNT4MEA

[VTC]

VITEK

Camera

[T]

Turret

[4]

4MP

[E]

Entry

Level

[M]

Motorized

[A]

Second

Iteration

[N]

Network

[T]

TRANSCENDENT
