www.vitekcctv.com

Transcendent Series 4 MegaPixel Fixed Lens IP WDR Dome

Camera with Knight Guard and Programmable Analytics

VTD-TND4FEA-2

*Also available in Charcoal,

VTC-TND4FEAB-2

TRANSCENDENT ANALYTICS!

AREA

Fully Programmable

Regional Intrusion

Detection

OBJECT TRACKING

Track Objects Removed

from or Abandoned in

Secure Areas

LINE CROSSING

Track People or

Vehicles Entering /

Exiting Designated

Areas

6/2025 : REV-1

CABLE CONNECTIONS

Ethernet (PoE), 12VDC

Input, Audio In*

TRANSCENDENTNETWORKINTEGRATED

AUDIO

4 MEGAPIXELMATRIX IR +

WHITE LIGHT

FIXED IRIS LENS

MICRO SD CARD SLOT

Supporting up to 256GB

MicroSD Cards

PROGRAMMABLE

ANALYTICS

VT-TJB03A

Optional Junction

box for Cable Man-

agement

VT-TFMT-S

In-ceiling Semi-flush

Mount

VT-TPDM-1

Pendant Mount (VT-

TJB03A Req)

VT-TPLMT

Universal Pole Mount

Adapter (VT-TJB03A

Req)

VT-TWMT3

Wall Mount

VT-TCNMT

Universal Corner

Mount Adapter (VT-

TJB03A Req)

VT-TWM04X

Wall Mount Bracket

4.69” (119mm)

3.44”

(87.4mm)

4.60” (117mm)

TRANSCENDENT KNIGHT GUARD IP CAMERA

WITH PROGRAMMABLE ANALYTICS!

Transcendent Series NDAA Compliant High Definition 4 Megapixel IP

Network Cameras offer unprecedented performance and value. These

simple, easy to install, attractively styled, IP Network Cameras transmit

over remote viewing via VMS, Web Browser, and iOS & Android

Apps. These models also feature enhanced night vision using White

Light emitters.

*Please research local, state and federal laws regarding

the implementation of audio surveillance.

KEY FEATURES

•

1/3” 4.0 MegaPixel CMOS Image Sensor

•

Up to 30fps@4MP (2560×1440)

•

2.8mm Fixed Iris Lens

•

Dual illumination with Matrix IR and Knight Guard white light (up

to 100’ Range)

•

True Wide Dynamic Range (120dB)

•

True Mechanical Day/Night function by ICR

•

XD-DNR (3D & 2D-DNR) Noise Reduction

•

Programmable Analytics: Line crossing / Region Intrusion

Detection (by human / vehicle classification), Object Abandoned

/ Missing, Scene Change Detection, Video Blur, Video Color

Cast Detection

•

H.265+ / H.265 / H.264+ / H.264 / MJPEG

•

MicroSD Card Slot for Local Recording (Up to 256GB)

•

1 Ch. Audio In + Built-in Mic*

•

Remote Viewing via VMS, Web Browser, and iOS & Android

Apps

•

ONVIF Compliant

•

IP67 Weather Resistance + IK10

•

Optional Junction Box (VT-TJB03A), Wall Mount (VT-TWMT3),

Pendant Mount (VT-TPDM-1 [reqs. VT-TJB03A]) and In-Ceiling

Semi Flush Mount (VT-TFMT-S) Available (See Additional

Mounting Options Below)

•

12VDC & PoE (Power over Ethernet) Operation

•

3-Year Warranty

OPTIONAL MOUNTS:
