VITEKCCTV.COM

(888) VITEK-70

VTC-TNT4RFA3

4 MegaPixel Advanced A.I. Fixed IP Turret Camera

Image Sensor

Image Size

Resolution

Min. Illumination

Lens

Day/Night

IR LEDs

IR Distance

Video Compression

Audio Compression

Main-Stream

Bit Rate

Wide Dynamic Range (WDR)

Digital Noise Reduction (DNR)

Quality

Image Setting

Intelligent Analytics

Smart Alarm

Region of Interest (ROI)

Audio

Local Storage

RS485

Remote Viewing

Supported Browsers

Connection Protocol

Weather

Power Input

Power Consumpt. (12VDC)

Power Consumpt. (PoE)

Working Environment

Weight

Dimensions

1/3” 4.0 Megapixel Progressive Scan CMOS

4 MegaPixel (2592 × 1520)

4 MP (2592 × 1520) / 3 MP (2304 × 1296) /

1080P (1920 × 1080) / 720P (1280 × 720) /

D1/CIF (480 × 240)

0 Lux (IR LED ON)

2.8mm or 3.6mm Fixed Iris Lens Options

True Day/Night by ICR

1 Matrix Style IR LED

Up to 100’

Smart H.265 / H.265+ / H.265 / Smart H.264 /

H.264+ / H.264 / MJPEG

G.711A / G.711U

4 MP, 2K, 3MP, 1080P, 720P

(60Hz: 1 ~ 30fps; 50Hz: 1~25fps )

HFR mode: 1080P / 720P( 60Hz: 1~60fps; 50Hz: 1~50fps)

64 Kbps ~ 8 Mbps

120dB Super WDR

3D-DNR

VBR (Five Levels of Adjustment) / CBR (Adjustable)

ROI, Saturation, Brightness, Chroma, Contrast,

Sharpen, NR; Adjustable through client software or web

browser

Face Detection, Target Counting, Intrusion, Region

Entrance / Exit, Line Crossing, Scene Change, Video Blur

Motion detection, SD card error, SD card full

Each ROI to be configured separately

Built-in Mic*, 1 Ch. Audio In

Built-in Micro SD card slot up to 256GB

× 1

CMS / Web Browser / Mobile (iOS/Android)

Internet Explorer, Chrome and Firefox with IE Tab

ONVIF

IP67

12VDC / PoE

120mA (LEDs Off) / 480mA (LEDs On)

< 7.5W

-22~140 / < 95% Humidity

18.70 oz. / 1.17 lbs. / 530g

3.77” x 4.25” (95.7 × 108mm) Dia × H

SPECIFICATIONS

*Please research local, state and federal laws regarding the

implementation of audio surveillance.

KEY FEATURES

• 1/3” 4.0 Megapixel CMOS Image Sensor

• Up to 30fps @ 4 MegaPixel (2592×1520)

• Available with 3.6 or 2.8mm Fixed Lens Configurations:

VTC-TNT4RFA3 (Ivory w/ 3.6mm), VTC-TNT4RFA3-2 (Ivory w/ 2.8mm),

VTC-TNT4RFA3B (Charcoal w/ 3.6mm),

VTC-TNT4RFA3B-2 (Charcoal w/ 2.8mm)

• Supports Still Image Recording Function

• 1 Matrix IR (up to 100’ IR Range)

• True Wide Dynamic Range

• True Mechanical Day/Night function by ICR

• 3D-DNR (Digital Noise Reduction)

• Fully Programmable Intelligent Analytics: Face Detection, Target

Counting, Intrusion, Region Entrance / Exit, Line Crossing, Scene

Change, Video Blur

• Built-in Mic*

• Smart H.265 / H.265+ / H.265 / Smart H.264 / H.264+ / H.264 / MJPEG

• Remote Viewing via CMS, Internet Explorer, and iOS & Android Apps

• ONVIF Compliant

• MicroSD Card Slot for Local Recording (256GB)

• IP67 Weather Resistance

• Optional Wall Mount (VT-TWMT-3) & Junction Boxes (VT-TJB01,

VT-TJB08) Available [See below for other mounting options]

• 12VDC & PoE (Power over Ethernet) Operation

• 3-Year Warranty

MOUNTS

VT-TJB01/B

Optional

Junction Box

for Cable

Management

VT-TJB08/B

Optional

Junction Box

for Cable

Management

VT-TWMT3/B

Optional Wall

Mount

RECORDERS

Pair with VITEK Transcendent Series

Network Recorders VT-TNR818PF,

VT-TNR1646PF, and VT-TNR3216PF

with Built-in PoE and Advanced

Analytics including Face Detection.

(888) VITEK-70 | WWW.VITEKCCTV.COM

28492 Constellation Road Valencia, CA

VT-TPLMT

Universal Pole

Mount Adapter

Ivory, reqs.

VT-TJB08

VT-TCNMT

Universal

Corner Mount

Adapter

Ivory, reqs.

VT-TJB08
