VITEKCCTV.COM

(888) VITEK-70

VTC-TNT4FL-2

Transcendent 4 MegaPixel Indoor/Outdoor

Fixed Lens WDR IP Turret Camera

SPECIFICATIONS

KEY FEATURES

• 1/2.7” 4.0 Megapixel CMOS Image Sensor

• Up to 30fps @ 4MP (2560 × 1440), 3MP (2304 × 1296), 1080P (1920 × 1080),

720P (1280 × 720), D1, CIF, 480 × 240

• 2.8mm Fixed Iris Lens

• Matrix IR with up to 100’ IR Range

• Digital Wide Dynamic Range (D-WDR)

• True Mechanical Day/Night function by ICR

• XD-DNR (3D & 2D-DNR) Noise Reduction

• Built-in Mic*

• Region Intrusion Detection, Scene Change Detection, Line Crossing, Object

Removal, Video Blur Detection

• H.265, H.264 Compression

• MicroSD Card Slot for Local Recording (Up to 128GB)

• Remote Viewing via CMS, Internet Explorer, and iOS & Android Apps

• ONVIF Compliant

• IP67 Weather Resistance

• Optional Junction Boxes (VT-TJB08, VT-TJB01), Wall Mounts (VT-TWMT-3,

VT-TWMT-A1), Pendant Mounts (VT-TPDMT-A1 [reqs. VT-TJB08],

VT-TPDM-2 [reqs. VT-TJB01] available. See more below.

• 12VDC & PoE (Power over Ethernet) Operation

• 2-Year Warranty

MOUNTS

RECORDERS

(888) VITEK-70 | WWW.VITEKCCTV.COM

28492 Constellation Road Valencia, CA

Image Sensor, Size 1/2.7” 4.0 Megapixel CMOS Image Sensor

Resolution 4MP(2560 × 1440), 3MP(2304 × 1296), 1080P(1920 × 1080),

720P(1280 × 720), D1, CIF, 480 × 240

Min. Illumination0.011 lux @F1.2, AGC ON; 0 lux with IR, 0.04 lux @ F2.2, AGC ON;

0 lux with IR

Lens 2.8mm Fixed Iris Lens

Day / Night True Day/Night by ICR

IR LEDs / IR Distance 1 Matrix / 100’

Video CompressionH.265 / H.264

Main-Stream 60Hz: 4MP/3MP/1080P (1~30fps), 50Hz : 4MP/3MP/1080P

(1~25fps)

Sub-Stream60Hz : 720P(1~15fps)/D1 /CIF (1~30fps), 50Hz: 720P(1~12fps)/

D1(1~25fps)/CIF (1~25fps)

Third Stream60Hz : D1/CIF/480x240 (1~30fps), 50Hz: D1/CIF/480x240 (1~25fps)

Bit Rate 64Kbps ~ 12Mbps

Bit Rate TypeVBR / CBR

Other Camera FeaturesBLC, HLC, Defog

Wide Dynamic Range

(WDR)

D-WDR (Digital Wide Dynamic Range)

Digital Noise Reduction

(DNR)

XD-DNR (2D-DNR & 3D-DNR)

Image Setting Saturation, Brightness, Chroma, Contrast, WDR, Noise reduction

Analytics Object Removal, Scene Change, Video Blur Detection, Intrusion and

Line Crossing

Smart Alarm Motion Alarm, SD Card Error, SD Card Full

Region of Interest (ROI) Each ROI to be Configured Separately

NetworkRJ45

AudioBuilt-in Mic*

StorageMicroSD Card Slot (128GB)

Remote ViewingCMS / Web Browser / Mobile (iOS/Android)

Supported BrowsersMicrosoft Internet Explorer

Connection Protocol ONVIF

Resistance IP67 Weather Rating

Power Input12VDC / PoE

Power Consumpt. (12VDC) 150mA (LEDs Off) / 320mA (LEDs On)

Power Consumpt. (PoE) < 5W

Working Environment -22° ~140° / < 95% Humidity

Weight

Dimensions: Dia × H

16.58 oz. / 1.04 lbs. / 460g

3.77” x 4.25” (95.7 × 108mm)

VT-TWMT3

Optional Wall

Mount

VT-TJB01

Optional

Junction Box

VT-TJB08

Optional

Junction Box

VT-TPDM-2

Universal 10”

Pendant Mount.

Reqs. VT-TJB01

VT-TWMT-A1

Wall Mount. Reqs.

VT-TJB08

VT-TPLMT

Universal Pole

Mount - Ivory, reqs.

VT-TJB08

VT-TCNMT

Universal Corner

Mount - Ivory,

reqs. VT-TJB08

VT-TPDMT-A1

Universal 10”

Pendant Mount.

Reqs. VT-TJB08

*Please research local, state and federal laws regarding the implementation of audio surveillance.

Pair with VITEK Transcendent

Series 6 and 8MP PoE NVRs in

4, 8, and 16 Ch. Configurations:

VT-TNR414PL, VT-TNR818PL,

VT-TNR1626PL

NDAA

COMPLIANT
