Features

Applications

Specifications

www.VikingElectronics.com

Information: 715-386-8861

VoIP Entry Phones

• Automatic polling and programming software included

• 2 Amp relay contacts for door/gate or SL-2 strobe light control

• Blue “Call Connected” LED indicator (E-30 / E-32-IP only)

• SIP compliant (see page 2 for list of compatible IP-PBX phone systems)

• Outbound Proxy, Authentication ID, Peer to Peer, VLAN Tagging

• PoE powered (class 1, <4 Watts)

• Automatic Noise Canceling (ANC) feature for proper operation in noisy environments

• VoIP eliminates the need for “Push to Talk” mode

• Network downloadable firmware

• T-10 Torx security screws for added security

• Can be used with optional RC-4A Secure Relay Controller (DOD 582)

• Handsfree operation

• Marine grade 316 stainless steel prevents corrosion on the stainless steel models

• Laser etched graphics on stainless steel models

• Programmable to dial up to 5 numbers on busy or ring no answer

• Cycles through backup phone numbers on busy or no-answer

• Optional Enhanced Weather Protection (EWP), EWP products are designed to meet IP66 Ingress

Protection Rating, see DOD 859

• Hangs up on busy signal, time-out or touch tone command

• Remotely programmable

• Extended temperature range (-40°F to 140°F)

• 3 different chassis or board only available

• Volume adjustments for microphone and speaker

• E-10-IP and E-30-IP are flush mountable using the included rough-in box or can be surface

mounted using an optional VE-5x5 Surface Mount Box (DOD 424)

• E-32-IP flush mounts in a standard double gang electrical box (not included)

• Optional SL-2 strobe light kit available (DOD 242)

• Diagnostics for testing microphone, speaker, and relay

Power: PoE class 1 (<4 watts)

Maximum Sound Pressure: 90 dB SPL @ 1m.

Dimensions: See Installation and Specifications

Operating Temperature: -40°F to 140°F (-40°C to 60°C)

Humidity - Standard Products: 5% to 95% non-condensing

Humidity - EWP Products: Up to 100%

Audio Codecs: G711u, G711a, G722

Network Compliance: IEEE 802.3 af PoE, SIP 2.0 RFC3261,

100BASE-TX with auto cross over

Regulatory Compliance:

FCC Part 15, Canada ICES-3 Class A, CE

(except for E-20-IP and E-20-IP-EWP)

Connections: (1) RJ45 10/100 Base-T, (3) gel-filled butt

connectors

Installation requires the assistance of a Network Administrator / IT Technician.

The E-10/20/30/32-IP VoIP Entry Phones are designed to provide quick and reliable

handsfree communication for SIP VoIP phone systems with PoE. The E-10/20/30/32-IP

entry phones can be programmed from any Touch Tone phone, PC, or remotely using a

static IP address. The Entry phones can dial up to 5 programmable numbers. On-board

2 Amp relay contacts are provided for activating doorstrikes or gate controllers. An optional

RC-4A Secure Relay Controller can also be used.

The E-30/32-IP entry phones will flash the “Call” LED during dialing and automatically

light the LED when the call is answered. All programming parameters, including phone

numbers and location numbers, are stored in non-volatile memory, requiring no batteries.

All units are PoE powered.

The E-10/20/30/32-IP-EWP shares all the features of the standard E-10/20/30/32-IP in

addition to Enhanced Weather Protection (EWP) for outdoor installations where the unit

is exposed to precipitation or condensation. EWP products are designed to meet IP66

standards and may feature foam rubber gaskets, sealed connections, gel-filled butt

connectors, as well as potted circuit boards with internally sealed, field-adjustable trim

pots and DIP switches for easy on-site programming. For more information on EWP, see

DOD 859.

E-10-IP / E-10-IP-EWP

Flush Mount, Black

Powder Painted Aluminum

E-20-IP / E-20-IP-EWP

Surface Mount, Light Grey

UV Stable Plastic Chassis

E-32-IP / E-32-IP-EWP

Flush Mount in a Standard

Double Gang Electrical Box,

Brushed 316 Stainless Steel

• Gate Entrance

• Parking ramps/lots

• ATM machines

• Medical centers

• Lobbies

• Entryways

• Stadiums

• Convention centers

• Public access areas

E-30-IP / E-30-IP-EWP

Flush Mount, Brushed 316

Stainless Steel (shown in optional

VE-5x5 Surface Mount Box)

PRODUCT

MANUAL

Designed, Manufactured and Supported in the USA

E-10/20/30/32-IP

VoIP Entry Phones

March 10, 2022

SECURITY & COMMUNICATION

VIKING

VoIP SIP System Compatibility

For compatibility and vendor specific detailed configuration instructions, see the Viking VoIP

SIP System Compatibility List, DOD 944. To open and download this PDF file:

1. Go to www.vikingelectronics.com

and enter 944 in the search box

2. Click Application Note (DOD 944)

to open and download the PDF

Scan the QR code below to open

and download the Viking VoIP

SIP System Compatibility List

- OR -

Important: Exclusion from this list means only that compatibility has not been verified, it does not mean

incompatibility. If you have questions, please call Viking Electronics at 715-386-8861.

Product specificaties

Merk:	Viking
Categorie:	Intercomsysteem
Model:	E-20-IP
Kleur van het product:	Wit
Gewicht:	750 g
Breedte:	140 mm
Diepte:	38 mm
Hoogte:	115 mm
Geluidsniveau:	90 dB
Plaatsing:	Muur
Connectiviteitstechnologie:	Bedraad
Luidspreker:	Ja
Certificering:	CE\nCanada ICES\nFCC Part 15\nSIP
Netwerkstandaard:	IEEE 802.3af
Aantal knoppen:	1
Buitenunit inbegrepen:	Ja
Gemakkelijk te installeren:	Ja
Outdoor units hoeveelheid:	1
Bedrijfstemperatuur (T-T):	-40 - 60 °C
Aansluiting type:	RJ-45
