Rev. 3/28/2017 PLB, MANUAL
Copyright 2017 Vestil Manufacturing Corp. Page 1 of 4
PLB-Series Wooden Pry Lever Bars
Instruction Manual
Receiving instructions:
After delivery, remove the packaging from the product. Inspect the product closely to determine whether it
sustained damage during transport. If damage is discovered, record a complete description of it on the bill
of lading. If the product is undamaged, discard the packaging.
NOTE:
The end-user is solely responsible for confirming that product design, installation, use, and maintenance
comply with laws, regulations, codes, and mandatory standards applied where the product is used.
Vestil Manufacturing Corp.
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
Fax: (260) 665-1339
www.vestilmfg.com e
-
mail:
info@vestil.com
Table of Contents:
Signal Words….……………………………………………………………..……………………………………………………. 2
Safe Use Recommendations…………………………..………………………………..…………………………..…….……. 2
Product Specifications…………………………………..…………………………………………………………..…….………2
Labeling Diagram……...…………………………………………..…………………………………………………………..…. 2
PLB exploded parts diagram & bill of materials………...…………………………………………………………….……….. 3
Assembly instructions……………………………………………………………………………………………………………. 3
Use instructions………………………………………………….……………………………………………….…………….. ... 3
Inspections………………………………………………………………………………………………………………………… 3
Maintenance……………………………………………………………………………………………………………………..…4
Limited Warranty…...…………………………………………………………………………………………………………..…. 4
Rev. 3/28/2017 PLB, MANUAL
Copyright 2017 Vestil Manufacturing Corp. Page 2 of 4
Signal Words
This manual uses SIGNAL WORDS to indicate the likelihood of personal injuries, as well as the probable seriousness of
those injuries, if the product is misused in the ways described. Other signal words call attention to uses of the product likely
cause property damage. The signal words used appear below along with the meaning of each word
:
Identifies a hazardous situation which, if not avoided, WILL result in DEATH or SERIOUS
INJURY. Use of this signal word is limited to the most extreme situations.
Identifies a hazardous situation which, if not avoided, COULD result in DEATH or
SERIOUS INJURY.
Indicates a hazardous situation which, if not avoided, COULD result in MINOR or
MODERATE injury.
Identifies practices likely to result in product/property damage, such as operation that might
damage the product.
Each person who assembles, installs, uses, or maintains this product should read the entire manual in advance and
fully understand the directions. If after reading the manual you do not understand an instruction, ask your
supervisor or employer for clarification, because failure to adhere to the directions in this manual might result in
serious personal injury.
Safe use recommendations:
Vestil diligently strives to identify foreseeable hazards associated with the use of its products. However, material
handling is inherently dangerous and no manual can address every conceivable risk. The most effective means for avoiding
injury is for the end user to apply sound judgment whenever using this device.
Improper use could result in serious personal injuries.
Failure to read and understand the entire manual before assembling, using or servicing the pry bar is a misuse of the
product. Read the manual to refresh your understanding of proper use and maintenance procedures.
DO NOT exceed the maximum rated load (see Label 287 on product; also shown below).
Only use the pry bar on improved surfaces (concrete or asphalt).
DO NOT apply more than 150 lb. downward force on the end of the handle.
DO NOT hang on, sit on, or bounce on the pry bar while attempting to tip or hold a load.
ALWAYS carefully watch the load on the pry bar.
Inspect the pry bar before each use (see “Inspections” and “Maintenance” sections on pp. 3, 4). DO NOT use the device
unless it is in satisfactory condition.
DO NOT use the pry bar to transport loads. Only use the bar to lift an edge or a corner of a load.
DO NOT lean over the pry bar while using it to lift a load.
DO NOT use the pry bar if it is damaged.
DO NOT modify the pry bar in any way. Unauthorized modifications automatically void the limited warranty (see p. 4)
and might make the product unsafe to use.
Product Specifications:
Model
Description
Handle
Length
Wheel
Dimensions
Wheel Type Capacity Net Weight
PLB-5
Wooden pry bar 5 ft. 5in. x 2in. Poly-on-steel
4,250 lb.
1,931.8 kg
32 lb.
14.2 kg
PLB-6
Wooden pry bar 6 ft. 5in. x 2in. Poly-on-steel
4,250 lb.
1,931.8 kg
33 lb.
14.7 kg
PLB-7
Wooden pry bar 7 ft. 5in. x 2in. Poly-on-steel
4,250 lb.
1,931.8 kg
34 lb.
15.2 kg
Labeling Diagram:
The product should always be labeled as
shown in the diagram to the right. Replace
any label that is damaged and/or not easily
readable.
Label 287: Model, serial no., capacity
(Applied to back side of axle)
