Pagina 1/11
TABLE OF CONTENTS Rev. 11/3/2021 FPG, MANUAL
TABLE OF CONTENTS Copyright 2021 Vestil Manufacturing Co. Page 1 of 11
FPG SERIES PORTABLE GANTRY CRANES
Receiving Instructions
After delivery, remove the packaging from the product. Inspect the product closely to determine
whether it sustained damage during transport. If damage is discovered, record a complete description of it
on the bill of lading. If the product is undamaged, discard the packaging.
NOTE:
The end-user is solely responsible for confirming that product design, use, and maintenance comply
with laws, regulations, codes, and mandatory standards applied where the product is used.
Technical Service & Replacement Parts
For answers to questions not addressed in these instructions and to order replacement parts, labels, and
accessories, call our Technical Service and Parts Department at (260) 665-7586. The Department can also
be contacted online at https://www.vestil.com/page-parts-request.php
.
Electronic Copies of Instruction Manuals
Additional copies of this instruction manual may be downloaded from
https://www.vestil.com/page-
manuals.php
Table of Contents
Page
Specifications……….……………………………………………………...…………………………………………...
2
Signal Words……………………………………………………………………………………………………………..
2
Safety Instructions……………………………...………………………………..……………………………………..
3
National Standards…………………………………………………………………………………………………….
3
FIG. 1: FPG-3 Exploded View and Bills of Materials……….…..………….……………………..……………….
4
FIG. 2: FPG-6 Exploded View and Bill of Materials……………………………………………………………….
4
FIG. 3: FPG-10 Exploded View and Bill of Materials……………………………………………………………...
5
FIG. 4: FPG-20 Exploded View and Bill of Materials……………………………………………………………...
5
Assembling the Crane.………………………………………………………………………………………………..
6 - 7
Using the Crane………………………………………………………………………………………………..……….
8
Record of Satisfactory Condition………………………………………….………………………………………..
9
Inspections and Maintenance……………………………………………………………………………………....
9
Labeling Diagram………………………………………………………..………………………………………….…
10
Limited Warranty…………………………………………………………………………………….…………………
11
VESTIL MANUFACTURING CORP.
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
Fax: (260) 665-1339
www.vestilmfg.com e-mail:
HUsales@vestil.comU
TABLE OF CONTENTS Rev. 11/3/2021 FPG, MANUAL
TABLE OF CONTENTS Copyright 2021 Vestil Manufacturing Co. Page 2 of 11
SPECIFICATIONS
Specifications for all FPG-series cranes, including dimensions, net weight, and capacity information, are
subject to change from time to time. To acquire the most up-to-date specifications for your unit,
download the appropriate specifications document from Vestil’s website as soon as you receive your
crane. To access the specifications document, navigate to this webpage:
https://www.vestil.com/product.php?FID=526
. Click the “Product Specifications Table” drop-down menu
bar partway down the page. Scroll down to the entry for the model you purchased and click the button
in the column titled “PDF’s” that looks like a pencil inside a box. A PDF file will open. This file is the
specifications document. Print a copy of the document and keep it with your copy of this manual. The
following is an exemplar specifications document for model FPG-3.
SIGNAL WORDS
This manual uses SIGNAL WORDS to indicate the likelihood of personal injuries, as well as the probable
seriousness of those injuries, if the product is misused in the ways described. Other signal words call
attention to uses of the product likely cause property damage. The following are signal words used in
this manual and their definitions.
DANGER
Identifies a hazardous situation which, if not avoided, WILL result in DEATH or
SERIOUS INJURY. Use of this signal word is limited to the most extreme situations.
WARNING
Identifies a hazardous situation which, if not avoided, COULD result in DEATH or
SERIOUS INJURY.
CAUTION
Indicates a hazardous situation which, if not avoided, COULD result in MINOR or
MODERATE injury.
NOTICE
Identifies practices likely to result in product/property damage, such as
operation that might damage the product.
!
!
!
