ASSEMBLY AND INSTALLATION

INSTRUCTIONS

T0597

Important to Know

1. Read all instructions carefully before installation and

operation.

2. If you are not familiar with state and local electrical codes,

it is recommended that you consult with a qualified

electrician.

3. Before installation, shut off power at the main fuse or

circuit breaker box. Be aware that simply turning off the

wall switch is not sufficient to prevent an electrical shock.

4. This fixture requires a 120V AC, 60 Hz power source.

5. Do not attempt to take the lantern apart; there are no

serviceable parts inside.

6. To avoid sensor damage by lightning or electrical surge,

make sure the grounding wire is securely connected.

7. For general safety and to avoid any possible damage to

the sensor, be sure the power is switched "off" before

replacing the bulb.

Maximum Wattage: 2~25W Incandescen Bulb

Work Temperature: -4ºF ~ 104ºF

Hardware Package (included):

W

Mounting Screw (B)Wire Connector (C)

Bolt Nut (D)Rubber Pad (E)

Mounting Plate Unit (A)

Max. 25W type B Bulb

(not included)

W

WARNING: Turn off the main power at circuit breaker before installing fixture.

AVERTISSEMENT: Coupez la source d’alimentation principale au panneau

central de disjoncteurs avant d’installer le luminaire.

NOTE: 1. Before installing, consult local electrical codes for wiring and grounding requirements.

2. READ

AND SAVE THESE INSTRUCTIONS.

Page 1 / 5

Glass Panel

Metal Frame

Clip

Fixture

Backplate

Wire Connector (C)

House Grounding Wire

Outlet Box

Mounting Screw (B)

Green Grounding Screw

Headless Screw

Mounting Plate Unit (A)

Fixture Wire

Rubber Pad (E)

Ball Nut (D)

Fixture Grounding Wire

Set Screw

8. Compatible with most LED dimmable bulb.

Features

1. Energy saving fixture.

2. Use dim-to-full brightness where dim-illumination

is preferred, such as your front entrance. Use

off-to-full brightness where off/on illumination is

preferred, such as your backyard.

3. When in manual override mode, use wall switch

to keep the light ON till dawn.

210317
